Anritsu 54169A
Integrated Scalar Network Analyser 10MHz - 40GHz.
DC to 50 GHz Frequency Range
2.4 mm (Male) Connector Type
50 Ohm Impedance
1.25 max VSWR
0.5 dB max at 50 GHz Insertion Loss
| Attribute | Value |
|---|---|
| Frequency Range | DC to 50 GHz |
| Connector Type | 2.4 mm (Male) |
| Impedance | 50 Ohm |
| VSWR | 1.25 max |
| Insertion Loss | 0.5 dB max at 50 GHz |
| Power Handling | 1 W average |
| Operating Temperature | -54°C to +125°C |
| Mating Cycles | 500 minimum |
| Material | Stainless Steel / Gold Plated contacts |
| Compatible Standards | IEEE 287, MIL-PRF-39012 |
Anritsu 54169A Options:
- 54169A - Option 1 - Rack Mounting with Slides
- 54169A - Option 2 - 70 dB RF Step Attenuator
- 54169A - Option 2A - 70 dB, 20 GHz Step Attenuator
- 54169A - Option 2B - 70 dB, 26.5 GHz Step Attenuator
- 54169A - Option 2C - 70 dB, 40 GHz Step Attenuator
- 54169A - Option 2D - 70 dB, 50 GHz Step Attenuator
- 54169A - Option 4 - 75 ohm source output (Available to 3.0 GHz)
- 54169A - Option 5 - Add Reference Channel
- 54169A - Option 6 - Add External Leveling
- 54169A - Option 7 - Internal Distance-To-Fault Software
- 54169A - Option 8 - Relative Group Delay Software
- 54169A - Option 12 - Add Front Panel Cover
- 54169A - Option 13 - Add Front Mounted Handles
- 54169A - Option 16 - +15 V DC Supply for Millimeter Wave Source Modules (Available with ≤ 20 GHz Models only)
- 54169A - Option 25 - Maintenance Manual
- 54169A - Option 26 - Extra Operation and GPIB Programming Manual
- 54169A - Option 33 - Ink-Jet Printer
| Model | 54169A |
|---|
The Anritsu 54169A is a scalar network analyzer covering 10 MHz to 40 GHz, providing transmission (dB), return loss, precise return loss, SWR, and power measurements. It supports Distance‑to‑Fault and group delay testing for advanced RF analysis in demanding applications.
Its compact form makes it ideal for production and quality assurance of RF devices such as filters, couplers, and amplifiers, offering reliable validation across a wide frequency range.
Testwall can supply the used Anritsu 54169A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu 54169A.
