Anritsu CMA5225
| Attribute | Value |
|---|---|
| Wavelengths Supported | 1310 nm and 1550 nm |
| Dynamic Range | Up to 35 dB |
| Measurement Functions | OTDR, Optical Loss Test Set (OLTS), Visual Fault Locator (VFL), and Power Meter |
| Fiber Type Compatibility | Single-mode fiber (SMF) |
| Display | Color LCD touchscreen display |
| Battery Life | Approximately 8 hours of continuous operation |
| Connector Interface | Universal adapter system supporting SC, LC, FC, and ST connectors |
| Data Storage | Internal memory with USB port for external storage transfer |
| Distance Range | Up to 200 km |
| Operating Temperature | -10°C to +50°C (14°F to 122°F) |
| Model | CMA5225 |
|---|
The Anritsu CMA5225 is a dual-wavelength OTDR module designed for the CMA5000a system, supporting 1310 nm and 1550 nm testing. It offers excellent sensitivity for splice and connector inspection while enabling precise fault location, distance-to-fault, reflectance, and ORL measurements. The module integrates seamlessly with the CMA5000a touchscreen chassis for efficient fiber validation.
Optimized for general-purpose single-mode fiber verification, the CMA5225 ensures reliable testing across standard telecom spans with dual-wavelength coverage and accurate fault detection.
Testwall can supply the used Anritsu CMA5225 Dual-Wavelength OTDR Module, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu CMA5225 Dual-Wavelength OTDR Module.
