Anritsu MA2474A
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 40 GHz |
| Sensor Type | Diode Power Sensor |
| Power Range | -70 dBm to -20 dBm |
| Connector Type | 2.92 mm (K-type) Male |
| Impedance | 50 Ohms |
| VSWR | 1.35 max (10 MHz to 40 GHz) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +71°C |
| Compatible Power Meters | Anritsu ML2430A Series, ML2480B Series |
| Calibration Factor Output | Stored calibration data via EEPROM |
Anritsu MA2474A Options:
- MA2474A - 760-209 - Hardside Transit Case
- MA2474A - D41310 - Soft Carry Case with Shoulder Strap
- MA2474A - MA2418A - 50 MHz Reference Oscillator with Power Supply
- MA2474A - ML2400A-01 - Rack Mount, single unit
- MA2474A - ML2400A-03 - Rack Mount, side by side
- MA2474A - ML2400A-05 - Front Bail Handle
- MA2474A - ML2400A-12 - Front Panel Cover
- MA2474A - ML2400A-20 - Spare 1.5m Sensor Cable
- MA2474A - ML2400A-21 - 0.3m Sensor Cable
- MA2474A - ML2400A-22 - 3m Sensor Cable
- MA2474A - ML2400A-23 - 5m Sensor Cable
- MA2474A - ML2400A-24 - 10m Sensor Cable
- MA2474A - ML2400A-25 - 30m Sensor Cable
- MA2474A - ML2400A-26 - 50m Sensor Cable
- MA2474A - ML2400A-27 - 100m Sensor Cable
- MA2474A - ML2400A-28 - RS232 Bootload Cable
- MA2474A - ML2400A-29 - Bulkhead Adapter
- MA2474A - ML2419A - Range Calibrator
- MA2474A - MA2497A - Agilent/HP84xxA Series Sensor Adaptor
- MA2474A - MA2499B - Anritsu 4700 & 4600 Series Sensor Adapter
| Model | MA2474A |
|---|
The Anritsu MA2474A diode authentication sensor covers 10 MHz to 40 GHz, offering a broad dynamic range of ~90 dB (–70 dBm to +20 dBm). With rise/fall times around 4 µs and EEPROM‑based calibration data storage, it ensures precise RF power measurements. Designed for accuracy and stability, it supports demanding broadband applications.
This sensor is well-suited for production testing, aerospace validation, and telecom system measurements, where speed and dynamic performance are critical.
Testwall can supply the used Anritsu MA2474A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MA2474A.
