Anritsu ML910B
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 40 GHz |
| Measurement Type | Optical Power Meter |
| Display Type | LCD Digital Display |
| Power Measurement Range | -70 dBm to +10 dBm |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Storage Temperature | -20°C to +60°C (-4°F to 140°F) |
| Power Supply | AC Adapter / Battery Operated |
| Interface | GP-IB / RS-232C |
| Wavelength Range | 800 nm to 1700 nm |
| Dimensions (W x H x D) | 240 mm x 90 mm x 310 mm |
Anritsu ML910B Options:
- ML910B - MA9801A - Optical Power Sensor, 0.38 to 1.15 mm, –90 to 0 dBm
- ML910B - MA9301A - Optical Power Sensor, 0.75 to 1.7 mm, –90 to 0 dBm
- ML910B - MA9802A - Optical Power Sensor, 0.38 to 1.15 mm, –65 to +10 dBm
- ML910B - MA9302A - Optical Power Sensor, 0.75 to 1.8 mm, –40 to +10 dBm
- ML910B - MA9807A - Feed-Through Power Sensor, 0.5 to 1.15 mm, –65 to +10 dBm, for optical fiber
- ML910B - MA9307A - Feed-Through Power Sensor, 0.75 to 1.7 mm, –60 to +3 dBm, for optical fiber
- ML910B - MA9305B - Optical Power Sensor, 0.75 to 1.7 mm, –60 to +3 dBm
- ML910B - MA9001A - Connector Adaptor with FC-type Connector, FC-type, for MA9802A or MA9302A
- ML910B - MA9001A-21 - Connector Adaptor with D4-type Connector, D4 type, for MA9802A or MA9302A
- ML910B - MA9013A - Fiber Adaptor with FC-type Plug, for fibers with 125 mm clad dia., 0.3 to 1 mm jacket dia.
- ML910B - MA9013A-21 - Fiber Adaptor with D4-type Plug, for fibers with 125 mm clad dia., 0.3 to 1 mm jacket dia.
- ML910B - MA9002A - Adaptor, for MA9802A or MA9302A (fits to the MP93A)
- ML910B - MP93A - Fiber Adaptor, for fibers with clad diameters of less than 150 mm, 0.8 to 1.0 mm jacket dia.
- ML910B - MA9805A - Optical Attenuator, used with MA9802A (attenuation: 10 dB)
- ML910B - MA9306A - Optical Attenuator, used with MA9302A (attenuation: 10 dB)
- ML910B - MA9005A-21 - Protective Connector Adaptor, D4-type, for MA9305B
- ML910B - J0377 - Sensor Connecting Cord E, for MA912A/B Optical Power Sensor
- ML910B - B0268 - Front Cover
- ML910B - J0007 - GPIB Cable, 1 m
- ML910B - J0008 - GPIB Cable, 2 m
| Model | ML910B |
|---|
The Anritsu ML910B Optical Power Meter offers dual independent channels with separate displays, supporting seven sensor types for a wide range of optical-power measurements. It enables precise relative measurements with 0.001 dB resolution and measures wavelengths from 0.38 to 1.8 mm, with high sensitivity down to -90 dBm at 1.3 mm. The built-in sensor capability allows direct readout of absolute optical power by simply specifying the wavelength, and up to 3,000 measured values can be stored for field operations.
This power meter is ideal for laboratory and field applications, supporting feed-through sensors to compensate for source fluctuations, delivering stable and accurate optical testing performance.
Testwall can supply the used Anritsu ML910B Optical Power Meter, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu ML910B Optical Power Meter.
