Anritsu
Anritsu MP1652A
50MHz - 3GHz Pulse Pattern Generator
Up to 12.5 Gbps Bit Rate
PRBS (2^7-1, 2^10-1, 2^15-1, 2^23-1, 2^31-1), Zero Substitution, User-Defined Patterns Data Pattern
0.5 V to 2.0 V (into 50 Ω) Output Amplitude
SMA Connector Output Interface
Internal / External Clock Source
| Attribute | Value |
|---|---|
| Bit Rate | Up to 12.5 Gbps |
| Data Pattern | PRBS (2^7-1, 2^10-1, 2^15-1, 2^23-1, 2^31-1), Zero Substitution, User-Defined Patterns |
| Output Amplitude | 0.5 V to 2.0 V (into 50 Ω) |
| Output Interface | SMA Connector |
| Clock Source | Internal / External |
| Input Sensitivity | 50 mV to 1.0 V (peak-to-peak) |
| BER Measurement | Built-in Bit Error Rate measurement capability |
| Operating Temperature | 0°C to 40°C |
| Power Supply | 100 to 240 VAC, 50/60 Hz |
| Interface / Connectivity | GPIB, RS-232 |
| Model | MP1652A |
|---|
The Anritsu MP1652A Pulse Pattern Generator offers variable clock and data signal amplitudes from 0.5 to 2 Vp-p, with offset adjustment within ±2 V. It enables precise amplitude and offset margin measurements, and features a high-quality waveform output with low FM/PM-noise clock generation via an N-Type connector.
This generator is ideal for pairing with the Anritsu MP1653A Error Detector for signal analysis and testing precision.
Testwall can supply the used Anritsu MP1652A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MP1652A.
