Anritsu MP1756A
| Attribute | Value |
|---|---|
| Bit Rate | Up to 12.5 Gbit/s |
| Data Pattern | PRBS (2^7-1, 2^10-1, 2^15-1, 2^23-1, 2^31-1), Zero Substitution, User-Defined Patterns |
| Output Amplitude | 0.5 V to 2.0 V (into 50 Ω) |
| Output Connector | SMA (female) |
| Rise/Fall Time | Less than 35 ps (20% to 80%) |
| Jitter (RMS) | Less than 1.5 ps RMS |
| Clock Source | Internal or External Reference Clock |
| Interface | GPIB, RS-232 |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Operating Temperature | 0°C to +50°C |
| Model | MP1756A |
|---|
The Anritsu MP1756A is a high-performance signal integrity test module engineered for differential signal analysis and high-speed transmission testing. Supporting data rates up to 12.5 Gbps, it offers differential and single-ended output, standard test pattern options, and precise clock/data alignment with delay adjustment.
Ideal for high-speed logic device characterization, the MP1756A ensures accurate and repeatable results. Its remote control capability allows seamless system integration for automated testing environments.
Testwall can supply the used Anritsu MP1756A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MP1756A.
