Anritsu MP1763A
| Attribute | Value |
|---|---|
| Bit Rate Range | 0.1 Gbit/s to 12.5 Gbit/s |
| Output Amplitude | 0.5 V to 2.0 V (into 50Ω) |
| Pattern Length | 2^7-1 to 2^31-1 PRBS, programmable word patterns |
| Rise/Fall Time | Less than 30 ps (20% to 80%) |
| Output Jitter (RMS) | Less than 2 ps RMS |
| Clock Source | Internal or External clock reference |
| Output Interface | Single-ended and differential outputs |
| Data Output Connector | 2.4 mm coaxial connector |
| Power Requirements | 100 to 240 VAC, 50/60 Hz |
| Operating Temperature | 0°C to 40°C |
| Model | MP1763A |
|---|
The Anritsu MP1763A is a high-performance BERT receiver designed for analyzing signals up to 12.5 Gbps, with high input sensitivity and rapid bit error detection. It offers BER windowing, error threshold alarms, and flexible clock recovery for accurate and reliable performance in demanding R&D environments.
Suitable for both manual and automated applications, the MP1763A provides versatile signal integrity testing capabilities, ensuring precision and adaptability for a range of measurement needs.
Testwall can supply the used Anritsu MP1763A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MP1763A.
