Anritsu MP1764
| Attribute | Value |
|---|---|
| Bit Rate Range | 0.1 Gbit/s to 12.5 Gbit/s |
| Pattern Length | 2^7-1 to 2^31-1 PRBS, programmable word patterns up to 2^32 bits |
| Input Sensitivity | 0.2 V to 1.0 V (peak-to-peak, differential) |
| Clock Input Frequency Range | 0.1 GHz to 12.5 GHz |
| Threshold Voltage Range | -2.0 V to +2.0 V |
| BER Measurement Range | 10^-1 to 10^-15 (error-free) |
| Data Input Interface | SMA connectors, differential data and clock inputs |
| Gating Function | Burst gate, error gate, and window gate measurement functions supported |
| Operating Temperature | 5°C to 40°C |
| Interface/Connectivity | GPIB (IEEE 488.2) and RS-232C remote control interfaces |
| Model | MP1764 |
|---|
The Anritsu MP1764 works seamlessly with the MP1763B Pulse Pattern Generator to detect errors and ensure compliance with ITU-T standards. It simplifies threshold and phase adjustments through a convenient one-touch auto-search function. With rapid error detection down to 0.1 seconds, 8 Mbit pattern synchronization, and zero wait-time counter gate, this unit is ideal for testing ultrahigh-speed logic ICs and digital communication systems.
Its advanced auto-search and synchronization capabilities enable quick and reliable evaluation, making it suitable for both research and development environments.
Testwall can supply the used Anritsu MP1764, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MP1764.
