Anritsu MS8601J
| Attribute | Value |
|---|---|
| Frequency Range | 100 Hz to 3 GHz |
| Resolution Bandwidth | 1 Hz to 3 MHz |
| Video Bandwidth | 1 Hz to 3 MHz |
| Display Dynamic Range | 100 dB |
| Phase Noise | -100 dBc/Hz at 10 kHz offset |
| Input Impedance | 50 Ohms |
| Maximum Input Level | +30 dBm |
| Sensitivity (DANL) | -145 dBm/Hz (typical) |
| Sweep Time | 10 ms to 1000 s |
| Power Supply | AC 100-240V, 50/60 Hz |
| Model | MS8601J |
|---|
The Anritsu MS8601J RF analyzer provides wide frequency coverage from approximately 9 kHz to 13 GHz, combining spectrum analysis, modulation measurement, and transmitter testing in one platform. It integrates precision power metering with ±0.4 dB accuracy, supports RF and I/Q (balanced or unbalanced) inputs, and utilizes high-speed digital signal processing to handle advanced telecom modes. With wideband signal measurement up to ~20 MHz RBW, it delivers versatile performance across diverse applications.
Optimized for development, production, and maintenance workflows, the Anritsu MS8601J excels in testing base-station and mobile transmitters. Remote control via GPIB, RS-232C, and Ethernet ensures seamless operation in both lab and field settings.
Testwall can supply the used Anritsu MS8601J, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MS8601J.
