Anritsu MT9080C
| Attribute | Value |
|---|---|
| Wavelength Range | 800 nm to 1700 nm |
| Dynamic Range | Up to 46 dB |
| Distance Range | Up to 320 km |
| Display | 5.7-inch color LCD touchscreen |
| Optical Connector Interface | Interchangeable optical connector adapters (FC, SC, ST, LC) |
| Battery Life | Approximately 7 hours of continuous operation |
| Data Storage | Internal memory plus USB and SD card external storage support |
| Communication Interfaces | USB, Ethernet (LAN), SD card slot |
| Operating Temperature | -10°C to +50°C (14°F to 122°F) |
| Weight | Approximately 1.5 kg (3.3 lbs) including battery |
| Model | MT9080C |
|---|
The Anritsu MT9080C configured for 1645–1655 nm targets higher‑wavelength fiber segments in exotic PON backhaul. It combines OTDR, power meter, light source, visible tracer, and fiber ID in one handheld unit. With ≈1 m event dead‑zone, 5 cm resolution, and ~26–38 dB dynamic range, it resolves short events and long spans. Telcordia‑compatible files, USB export, and waveform storage/comparison streamline QC reporting.
A single‑port connector and the intuitive Top Menu GUI let users switch modes quickly. Optional IP/Ethernet diagnostics extend troubleshooting across access, metro, and backhaul links.
Testwall can supply the used Anritsu MT9080C, fully tested. With expert support and global delivery, Testwall ensures high‑performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MT9080C.
