Anritsu S331D
| Attribute | Value |
|---|---|
| Frequency Range | 25 MHz to 4000 MHz (4 GHz) |
| Return Loss / VSWR Measurement Range | 0 to 60 dB return loss / 1.00 to infinity VSWR |
| Cable Loss Measurement Range | 0 to 30 dB |
| Distance-to-Fault (DTF) Range | Up to 2000 meters (depending on cable type) |
| Dynamic Range | 60 dB |
| Data Points | Up to 1000 data points per sweep |
| Display | 7-inch color LCD touchscreen display |
| Battery Life | Approximately 2 hours with internal rechargeable battery pack |
| RF Connector | Type N (female), 50 ohm |
| Operating Temperature | -10°C to +55°C (14°F to 131°F) |
Anritsu S331D Options:
- S331D - Option 2 - 2 MHz frequency extension
- S331D - Option 5 - Power Monitor - requires external detector
- S331D - Option 16 - 6 GHz frequency extension, Cable & Antenna Analyzer
- S331D - Option 19 - High Accuracy Power Meter (PSN50 sensor not included)
- S331D - Option 29 - Power Meter - does not require external detector
- S331D - Option 31 - GPS Receiver for location information. Includes GPS antenna
- S331D - Option 50 - T1/E1 Analyzer - cannot be ordered with Option 5
| Model | S331D |
|---|
The Anritsu Site Master S331D covers 25 MHz to 4000 MHz, offering precise Return Loss/SWR, Cable Loss, and Distance-To-Fault measurements. It features optional T1/E1 and power meter capabilities with patented RF interference rejection for reliable operation in high RF environments. Ideal for VHF, broadcasting, paging, cellular, PCS/GSM, 3G, ISM, WLAN, and WLL applications.
With advanced data analysis software, users can monitor trends, diagnose faults, and generate professional reports for efficient wireless system management.
Testwall can supply the used Anritsu Site Master S331D, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu Site Master S331D.
