Fluke 7340
| Attribute | Value |
|---|---|
| Temperature Range | -45°C to 150°C (-49°F to 302°F) |
| Temperature Stability | ±0.005°C |
| Temperature Accuracy | ±0.03°C |
| Display Resolution | 0.001°C |
| Bath Fluid Capacity | 4 liters |
| Heating Capacity | 250W |
| Cooling Capacity | 120W at 20°C |
| Power Requirements | 115/230 VAC, 50/60 Hz, 7A/3.5A |
| Operating Environment | 5°C to 40°C ambient temperature, up to 80% relative humidity (non-condensing) |
| Dimensions (W x D x H) | 21.6 cm x 35.6 cm x 38.1 cm (8.5 in x 14 in x 15 in) |
Fluke 7340 Options:
- 7340 - 230V - 230 VAC (±10%), 50 Hz, 8 amps optional power
- 7340 - IEEE-488 - IEEE-488 Interface (optional, RS-232 included as standard)
| Model | 7340 |
|---|
FLUKE 7340 Compact Temperature Calibration Baths
The Fluke 7340 Compact Temperature Calibration Bath is a versatile bench-top constant temperature bath ideal for temperature calibration and applications demanding precise temperature stability. It employs an advanced solid-state temperature controller with micro-controller technology to ensure precision thermometer testing, stability and uniformity.
The Fluke 7340 bath offers digital remote communication through standard RS-232 and optional IEEE-488 interfaces. The Fluke 7340 performs reliably across a wide temperature range from -40 °C to 150 °C, the refrigeration permits sub-ambient temperature control. Key features include rapid heating and cooling, temperature scan rate control, ramp and soak functions, memory for eight set-points, adjustable readout in C or F, and automatic refrigeration control.
Specifications for the FLUKE 7340 Compact Temperature Calibration Baths Include:
| Temperature Range | -40 C to 150 C |
| Heating Time | 25 C to 150 C (60 min) (oil 5012) |
| Cooling Time | 25 C to -40 C (110 min) (ethanol) |
| Digital Setting Accuracy | ± 0.5 C |
