Crystal Engineering XP2-1000
| Attribute | Value |
|---|---|
| Pressure Range | 0 to 1000 psi (0 to 68.95 bar) |
| Accuracy | ±0.1% of full scale |
| Display | Graphical LCD with backlight |
| Pressure Units | psi, bar, mbar, kPa, MPa, inHg, mmHg, inH2O, cmH2O, kg/cm² |
| Battery Life | Up to 1500 hours with standard AA batteries |
| Data Logging | Up to 32,000 readings with date and time stamp |
| Communication Interface | USB and RS-232 |
| Operating Temperature | -10°C to 50°C (14°F to 122°F) |
| Pressure Connection | 1/4 inch NPT male |
| Ingress Protection | IP67 rated (dust-tight and waterproof up to 1 meter) |
Crystal Engineering XP2-1000 Options:
- XP2-1000 - DD - Dual Display
- XP2-1000 - S2 - 0.02% of Full Scale accuracy (15 to 25°C)
- XP2-1000 - S5 - 0.05% of Full Scale accuracy
- XP2-1000 - BSP - G 1/4 B BSP adapter type
- XP2-1000 - M20 - M20x1.5 adapter type
- XP2-1000 - RP - Back connection location
- XP2-1000 - F4 - Panel mount connection location
- XP2-1000 - DL - DataLogging (32,000 data points, non-volatile flash memory)
- XP2-1000 - AXX - System A pump system (0 to 30 psi/2 bar, pneumatic hand pump), aluminum case
- XP2-1000 - AHX - System A pump system (0 to 580 psi/40 bar, pneumatic hand pump), aluminum case
- XP2-1000 - BXX - System B pump system (-25 inHg to 30 psi, pneumatic hand pump), aluminum case
- XP2-1000 - BHX - System B pump system (-27 inHg to 580 psi, pneumatic hand pump), aluminum case
- XP2-1000 - CXX - System C pump system (0 to 3000 psi/200 bar, hydraulic oil hand pump), aluminum case
- XP2-1000 - CHX - System C pump system (0 to 5000 psi/350 bar, hydraulic oil hand pump), aluminum case
- XP2-1000 - DOX - System D pump system (0 to 5000 psi/350 bar, hydraulic oil bench top), aluminum case
- XP2-1000 - DWX - System D pump system (0 to 5000 psi/350 bar, hydraulic water bench top), aluminum case
- XP2-1000 - EOX - System E pump system (0 to 10,000 psi/700 bar, hydraulic oil bench top), aluminum case
- XP2-1000 - FOV - System F pump system (0 to 15,000 psi/1000 bar, hydraulic oil bench top), aluminum case
- XP2-1000 - FWV - System F pump system (0 to 15,000 psi/1000 bar, hydraulic water bench top), aluminum case
- XP2-1000 - GOX - System G pump system (0 to 15,000 psi/1000 bar, hydraulic oil bench top), waterproof case
- XP2-1000 - GWX - System G pump system (0 to 15,000 psi/1000 bar, hydraulic water bench top), waterproof case
- XP2-1000 - HOX - System H pump system (-27 inHg to 580 psi and 0 to 5000 psi/350 bar), waterproof case
- XP2-1000 - W - Waterproof carrying case (Pelican Case)
| Model | XP2-1000 |
|---|
The Crystal Engineering XP2I-1000 Digital Pressure Gauge delivers ultra-rugged, intrinsically safe performance with 0.1% reading accuracy and a 1000 psi range. Featuring a 5.5-digit display, 32,000 data point recording, and easy three-button control, it ensures precision in demanding environments. Its polycarbonate lens and elastomer-mounted circuitry provide shock and impact resistance, while the unit remains accurate even when dropped, submerged, or over-pressurized.
With long battery life, ultra-low power mode, and intrinsic safety, the XP2I-1000 offers seamless year-long data logging without external power needs. It is fully temperature-compensated, making it suitable for wide-ranging industrial pressure measurement applications.
Testwall can supply the used Crystal Engineering XP2I-1000 Digital Pressure Gauge, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Crystal Engineering XP2I-1000 Digital Pressure Gauge.
