Crystal Engineering XP2I-500
| Attribute | Value |
|---|---|
| Pressure Range | 0 to 500 psi |
| Accuracy | ±0.1% of full scale |
| Display | 4-digit LCD display |
| Pressure Units | psi, bar, mbar, kPa, MPa, inHg, mmHg, inH2O, cmH2O, kg/cm² |
| Battery Life | Approximately 2000 hours with standard alkaline batteries |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Pressure Port Connection | 1/4 inch NPT male |
| Ingress Protection | IP67 rated (dust-tight and waterproof) |
| Power Supply | 9V alkaline battery (NEDA 1604A / IEC 6LR61) |
Crystal Engineering XP2I-500 Options:
- XP2I-500 - -DD - Dual Display
- XP2I-500 - -S2 - 0.02% of Full Scale accuracy (15 to 25°C), ±0.05% of Full Scale (-10 to 15°C, 25 to 50°C, typical)
- XP2I-500 - -S5 - 0.05% of Full Scale accuracy (-10 to 50°C)
- XP2I-500 - -BSP - G 1/4 B BSP adapter fitting
- XP2I-500 - -M20 - M20x1.5 adapter fitting
- XP2I-500 - -RP - Back connection location
- XP2I-500 - -F4 - Panel mount connection
- XP2I-500 - -DL - Datalogging (DataLoggerXP firmware)
- XP2I-500 - -AXX - System A pump system (0 to 30 psi/2 bar, pneumatic hand pump), aluminum case
- XP2I-500 - -AHX - System A pump system (0 to 580 psi/40 bar, pneumatic hand pump), aluminum case
- XP2I-500 - -BXX - System B pump system (-25 inHg to 30 psi, pneumatic hand pump), aluminum case
- XP2I-500 - -BHX - System B pump system (-27 inHg to 580 psi, pneumatic hand pump), aluminum case
- XP2I-500 - -CXX - System C pump system (0 to 3000 psi/200 bar, hydraulic oil hand pump), aluminum case
- XP2I-500 - -CHX - System C pump system (0 to 5000 psi/350 bar, hydraulic oil hand pump), aluminum case
- XP2I-500 - -DOX - System D pump system (0 to 5000 psi/350 bar, hydraulic oil bench top), aluminum case
- XP2I-500 - -DWX - System D pump system (0 to 5000 psi/350 bar, hydraulic water bench top), aluminum case
- XP2I-500 - -EOX - System E pump system (0 to 10,000 psi/700 bar, hydraulic oil bench top), aluminum case
- XP2I-500 - -FOV - System F pump system (0 to 15,000 psi/1000 bar, hydraulic oil bench top), aluminum case
- XP2I-500 - -FWV - System F pump system (0 to 15,000 psi/1000 bar, hydraulic water bench top), aluminum case
- XP2I-500 - -GOX - System G pump system (0 to 15,000 psi/1000 bar, hydraulic oil bench top), waterproof case
- XP2I-500 - -GWX - System G pump system (0 to 15,000 psi/1000 bar, hydraulic water bench top), waterproof case
- XP2I-500 - -HOX - System H pump system (-27 inHg to 580 psi pneumatic and 0 to 5000 psi hydraulic oil), waterproof case
- XP2I-500 - -W - Waterproof carrying case (Pelican Case)
| Model | XP2I-500 |
|---|
The Crystal Engineering XP2I-500 Digital Pressure Gauge is an ultra-rugged, intrinsically safe device delivering 0.1% reading accuracy. It features a wide 0–500 psi range, 0.01% resolution, and advanced temperature compensation for consistent precision in extreme conditions. The gauge offers exceptional durability with shock-resistant elastomer-mounted circuitry, polycarbonate lens protection, and the ability to withstand drops, submersion, and overpressure without losing accuracy.
Engineered for user-friendly operation, the XP2I-500 eliminates complex menus, requiring only three buttons for full functionality. It logs up to 32,000 data points and supports ultra-low power mode, enabling a year-long operation on a single set of batteries without external supplies.
Testwall can supply the used Crystal Engineering XP2I-500, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Crystal Engineering XP2I-500.
