SKU
83137
100 kHz to 4 GHz (MS2712E)
100 kHz to 6 GHz (MS2713E)
One-button measurements: ACPR, Channel Power, Field Strength, Occupied BW, AM/FM/SSB Demod
Interference Analyzer: Spectrogram, Signal Strength, RSSI, Signal ID
3GPP Signal Analyzers: GSM/EDGE, W-CDMA/HSDPA, TD-SCDMA/HSDPA, LTE
3GPP2 Signal Analyzers: cdmaONE/CDMA2000 1X, CDMA2000 1xEV-DO
IEEE 802.16 Signal Analyzers: Fixed WiMAX, Mobile WiMAX
ISDB-T Signal Analyzer
DANL: > -162 dBm typical DANL (normalized to 1 Hz)
Dynamic range: >95 dB
+33 dBm TOI typical @ 6 GHz
Phase Noise: -100 dBc/Hz @ 10 kHz offsetequency accuracy: < ? 50 ppb with GPS on
Detection methods: Peak, RMS, Negative, Sample, Quasi-peak
Save-on-event: Automatically saves a sweep when crossing a limit line or at the end of the sweep.
Gated sweep: View pulsed or burst signals only when they are on, or off.
Three hours of battery life
Touch-screen display
USB port
8.4-inch Touchscreen TFT display
Lightweight: <3.45 kg
