California Instruments
California Instruments 1503L-RT
1500 VA Potencia de salida
0 - 300 V CA (monofásico) Tensión de salida
45 Hz - 500 Hz Frecuencia de salida
6 A a 250 V Corriente de salida máxima
115 V / 230 V CA, 50/60 Hz Tensión de entrada
| Atributo | Valor |
|---|---|
| Potencia de salida | 1500 VA |
| Tensión de salida | 0 - 300 V CA (monofásico) |
| Frecuencia de salida | 45 Hz - 500 Hz |
| Corriente de salida máxima | 6 A a 250 V |
| Tensión de entrada | 115 V / 230 V CA, 50/60 Hz |
| Forma de onda de salida | Senoidal de baja distorsión |
| Distorsión armónica total (THD) | Menos del 0,5% |
| Interfaz de programación | IEEE-488 (GPIB) e interfaz RS-232 |
| Regulación de tensión | ± 0,1% de la tensión nominal de salida |
| Dimensiones (An x Al x Pr) | 425 mm x 132 mm x 550 mm (formato rack 3U) |
California Instruments 1503L-RT Options:
- 1503L-RT - -P - Programmable controller (single phase)
- 1503L-RT - -3P - Programmable controller (three phase)
- 1503L-RT - -PT - Fast Transient programmable controller (single phase)
- 1503L-RT - -3PT - Fast Transient programmable controller (three phase)
- 1503L-RT - -M - Manual control oscillator (single phase)
- 1503L-RT - -3M - Manual control oscillator (three phase)
- 1503L-RT - -MODE - Allows IEEE-programmed or switch configured single-phase or three-phase output
- 1503L-RT - -MT - Military applications; CIIL and full confidence test
- 1503L-RT - -RPV - Allows amplitude to be programmed with an external 0-10 VDC input (manual oscillator)
- 1503L-RT - -SQW - Square wave capability with programmable controller
- 1503L-RT - -704 - MIL-STD-704 test routines embedded in -P and -PT controller
- 1503L-RT - -160 - RTCA/DO-160 test routines embedded in -PT controller
- 1503L-RT - -HV - High voltage; changes output transformer to 156 V / 312 V, L-N
- 1503L-RT - -EHV - Extra high voltage; changes output transformer to 200 V / 400 V, L-N (45 Hz to 1000 Hz only)
- 1503L-RT - -LV - Low voltage; changes output transformer to 67.5 V / 135 V, L-N
- 1503L-RT - -AX - Separate isolated 26 VAC regulated and 5 VAC unregulated auxiliary outputs
- 1503L-RT - -LKM - Clock/Lock Master Unit; hardware to adapt to one slave unit
- 1503L-RT - -LKS - Clock/Lock Slave Unit; hardware to accept Clock/Lock inputs from LKM unit
- 1503L-RT - 210960 - Rack slides; required for mounting in 19" (483 mm) instrument rack
| Model | 1503L-RT |
|---|
