California Instruments 6000L
| Atributo | Valor |
|---|---|
| Potencia de salida | 6000 VA |
| Tensión de salida | 0 - 300 V AC |
| Frecuencia de salida | 45 Hz - 500 Hz |
| Número de fases | Monofásico |
| Tensión de entrada | 208 V / 230 V AC |
| Corriente de salida máxima | 20 A |
| Distorsión armónica total (THD) | Menos del 0,5% |
| Interfaz de comunicación | GPIB / RS-232 |
| Dimensiones (An x Al x Pr) | 425 mm x 132 mm x 635 mm |
| Peso | Aproximadamente 34 kg |
California Instruments 6000L Options:
- 6000L - -P - Programmable controller (single phase)
- 6000L - -PT - Fast Transient programmable controller (single phase)
- 6000L - -M - Manual control oscillator (single phase)
- 6000L - -3P - Programmable controller, three phase
- 6000L - -3PT - Fast Transient programmable controller, three phase
- 6000L - -3M - Manual control oscillator, three phase
- 6000L - -MODE - Allows IEEE-programmed or switch configured single-phase or three-phase output
- 6000L - -MT - Military applications; CIIL and full confidence test
- 6000L - -RPV - Allows amplitude to be programmed with an external 0-10 VDC input (manual oscillator)
- 6000L - -704 - MIL-STD-704 test routines embedded in -P and -PT controller
- 6000L - -HV - High voltage; changes output transformer to 156 V / 312 V, L-N
- 6000L - -EHV - Extra high voltage; changes output transformer to 200 V / 400 V, L-N (45 Hz to 1000 Hz only)
- 6000L - -LV - Low voltage; changes output transformer to 67.5 V / 135 V, L-N
- 6000L - -UP - Accepts 3-phase L-L voltage from 342 V to 456 V, L-L
- 6000L - -LKM - Clock/Lock Master Unit; installs hardware to adapt to one slave unit
- 6000L - -LKS - Clock/Lock Slave Unit; installs hardware to accept Clock/Lock inputs from LKM unit
- 6000L - 210960 - Rack slides; required for mounting in 19" (483 mm) instrument rack
| Model | 6000L |
|---|
California Instruments 6000L AC Power Source
The California Instruments 6000L AC power source is ideal for applications where small size, low heat dissipation and light weight are important. All 6000L AC sources are completely self-contained, while control is through an embedded oscillator. With a programmable controller, California Instruments 6000L provides the most comprehensive set of programmable functions in the industry.
The small size of the California Instruments 6000L AC power source provides more power per inch than most other AC supplies. Users are able to measure and record key output parameters such as volt rms, current, peak current, real power, and power factor. Easily control all output parameters such as voltage, cur limit, phase and frequency. The broad range of programmable functions available with the 6000L AC source allows users to test for virtually any line occurrence. Automatic remote calibration and comprehensive self-tests simplify maintainability.
Specifications of the California Instruments 6000L AC Power Source includes:
| AC Power | 6000VA |
| Voltage Low/High | 0-135V/0-270V |
| Frequency | 45-440Hz |
| Cur RMS/Peak | 44.4Arms/157.4A |
| Power Factor | 0 to 1 |
See Datasheet for Full Specifications
