Chroma
Chroma 6560
AC Source, 6KVA, 0-500V, 15 - 2 kHz, 1 Phase (parallel or series)
0 ~ 600 V Rango de voltaje de salida
0 ~ 10 A Rango de corriente de salida
1800 W Potencia máxima de salida
15 Hz ~ 1000 Hz Frecuencia de salida
≤ 0,5% (carga lineal) Distorsión armónica total (THD)
| Atributo | Valor |
|---|---|
| Rango de voltaje de salida | 0 ~ 600 V |
| Rango de corriente de salida | 0 ~ 10 A |
| Potencia máxima de salida | 1800 W |
| Frecuencia de salida | 15 Hz ~ 1000 Hz |
| Distorsión armónica total (THD) | ≤ 0,5% (carga lineal) |
| Voltaje de entrada | 180 V ~ 250 V CA, monofásico |
| Interfaz de comunicación | GPIB / RS-232 |
| Modos de operación | CA, CC, CA+CC |
| Dimensiones (An × Al × Pr) | 430 mm × 133 mm × 500 mm |
| Peso | 28 kg |
Chroma 6560 Options:
- 6560 - 6560-2 - Programmable AC Source 0~500V/45~1KHz / 6KVA I/P 3Ø 220V
- 6560 - 6560-3 - Programmable AC Source 0~500V/45~1KHz / 6KVA I/P 3Ø 380V
- 6560 - A650001 - Remote Interface for Model 6500 Series (External V Reference, RS-232 interface, Printer Interface, GPIB Interface, Special I/O Port, System I/O Port)
- 6560 - A650003 - Softpanel for Model 6500 Series
- 6560 - A610004 - Universal Socket Center for Model 6512/6520/6530/6560 Series
- 6560 - A600009 - GPIB Cable (200cm)
- 6560 - A600010 - GPIB Cable (60cm)
| Model | 6560 |
|---|
Chroma 6560 AC Power Source The Chroma 6560 Programmable AC Power Source delivers the right solution to simulate all kinds of normal/abnormal input conditions and measure the critical characteristics of the products under test. . It is suitable for commercial applications (47-63Hz) such as avionics, marine, and military applications at 400Hz or higher frequency; or for electrical motor, air conditioner test applications at 20Hz. The Chroma 6560 AC source generates a very clean sine or square waveforms output with typical distortion less than 0.5%. Testing for compliance to AC line harmonic immunity standards can be easily achieved with the Chroma 6560 AC source. It also can simulate all kinds of power line disturbances such as cycle dropout, transient spike, brown out, phase angle, voltage and frequency ramp up (ramp down), etc. The Chroma 6560 AC Power Source has built in powerful Direct Digital Synthesis (DDS) waveform generator to provide low distortion (0.5%) sine or square waveform over a maximum frequency range from 15 to 2000Hz, with 0.01Hz (15 - 99.99Hz) resolution and 0.15% accuracy. Users can install the software in computer to control the AC source via IEEE488 and RS-232. Specifications of the Chroma 6560 AC Power Source includes: See Datasheet for Full Specifications
