Espec SH-642
Temperature & Humidity Chamber, -40C to 150C, 2.2 Cu Ft
-40°C a +150°C Rango de temperatura
20% HR a 98% HR Rango de humedad
642 litros Volumen interior
±2°C Uniformidad de temperatura
±3% HR Uniformidad de humedad
| Atributo | Valor |
|---|---|
| Rango de temperatura | -40°C a +150°C |
| Rango de humedad | 20% HR a 98% HR |
| Volumen interior | 642 litros |
| Uniformidad de temperatura | ±2°C |
| Uniformidad de humedad | ±3% HR |
| Dimensiones interiores (An x Al x Pr) | 1000 mm x 900 mm x 713 mm |
| Alimentación eléctrica | 200/208/220 V, trifásico, 50/60 Hz |
| Consumo eléctrico | Aproximadamente 6,0 kVA |
| Sistema de refrigeración | Compresor hermético de dos etapas con refrigerante R404A/R23 |
| Normas de cumplimiento | IEC 60068, JIS C 60068 |
Espec SH-642 Options:
- SH-642 - R-449A - Low GWP Refrigerant (available on request, in place of standard R-404A)
- SH-642 - 220V-C - Power Plug 220V AC, C type
- SH-642 - 220V-O - Power Plug 220V AC, O type
- SH-642 - CONT-WS - Continuous Water Supply, Connection port with pressure-reducing valve
- SH-642 - CONT-WS2 - Continuous Water Supply, Connection port without pressure-reducing valve
- SH-642 - ROOF-WT - Roof Top Water Tank, effective water volume 5L
- SH-642 - AUTO-WR - Automatic Water Refill
- SH-642 - WET-WICK - Wet-Bulb Wick (1 box, 24 wicks, 1 dropper)
- SH-642 - VIEW-DOOR - Door with Viewing Window (LED light, W215×H290mm effective view)
- SH-642 - ROOF-VIEW - Roof Top Viewing Window (effective view W181×D107mm)
- SH-642 - INNER-GLASS - Inner Glass Door
- SH-642 - HAND-IN - Hand-In Port (φ130mm, select left or right side)
- SH-642 - ADD-PORT - Additional Cable Port (left/right side or ceiling; φ25, φ50, φ100, or flat W100×H25mm)
- SH-642 - PORT-PLUG - Cable Port Rubber Plug (for φ25, φ50, φ100, flat, φ50 with slits, φ100 with slits, or spiral-wrapped)
- SH-642 - EZ-PORT - EZ Connect Cable Port Plug (embedded terminals, AC 6-24V / DC 1.5-60V, 0.1-3A, Block 10P)
- SH-642 - SHELF - Additional Shelf, 18-8 Cr-Ni Stainless Steel (5kg load capacity, max 5 stages, pitch 50mm)
- SH-642 - BASKET - Specimen Basket, 18-8 Cr-Ni Stainless Steel, W206×H40×D156mm
- SH-642 - CABLE-KIT - Cable Organizer Kit (cable ties, magnetic cable cover, dew tray)
- SH-642 - NOISE-CVR - Noise Reduction Rear Cover
- SH-642 - RS485 - RS-485 Interface
- SH-642 - RS232C - RS-232C Interface
- SH-642 - GPIB - GPIB Interface
- SH-642 - CABLE-RS485 - RS-485 Communication Cable (5m, 10m, or 30m)
- SH-642 - CABLE-GPIB - GPIB Communication Cable (2m or 4m)
- SH-642 - PAPERLESS - Paperless Recorder (5.7-inch color touch panel, temperature & humidity type or temperature type)
- SH-642 - RECORDER - Temperature/Humidity Recorder, portable dot type, effective width 100mm
- SH-642 - EXT-OUT-X3 - External Output Terminal Set ×3 (time up output, time signal terminal, temp & humidity SP attainment output)
- SH-642 - WB-TEMP-OUT - Temperature Recorder Output Terminal (Wet-Bulb Temperature)
- SH-642 - THERMOCOUPLE - Thermocouple with Brass Ball Tip, Type T (2m, 4m, or 6m)
- SH-642 - DC-PWR - Applying DC Power Supply (5V, 12V, 15V, 24V, or 48V)
- SH-642 - OPT-BOX - Option Box (for paperless recorder, external output terminal set, specimen temperature control, DC power supply)
- SH-642 - SPEC-TEMP - Specimen Temperature Control (insulated type)
- SH-642 - CAP-HUMID - Electrostatic Capacitance-Type Humidity Sensor Control (0-100%rh, ±2%rh accuracy)
- SH-642 - AIRFLOW - Airflow Adjuster (4 setting levels)
- SH-642 - OVERCOOL - Overcool Protector
- SH-642 - EXT-ALARM - External Device Alarm Input Terminal
- SH-642 - DOOR-SIG - Door Opening Signal Output Terminal
- SH-642 - STATUS-LT - Status Indicator Light (up to 4 levels, pole length 226mm, with or without buzzer)
- SH-642 - ESTOP - Emergency Stop Pushbutton (with or without guard)
- SH-642 - DEW-TRAY - Chamber Dew Tray
- SH-642 - MAN-CD - Operation Manual, CD
- SH-642 - MAN-BOOK - Operation Manual, Booklet
- SH-642 - RPT-INSPECT - Testing and Inspection Report
- SH-642 - RPT-DATA - Test Data Report
- SH-642 - RPT-UNIFORM - Temperature & Humidity Uniformity Measurement Report
- SH-642 - RPT-CALIB - Calibration Report
- SH-642 - RPT-CERT - Calibration Certificate
- SH-642 - RPT-TRACE - Traceability System Chart
- SH-642 - RPT-TRACECERT - Traceability Certificate
- SH-642 - STAND - Stand Variation (C dolly type, L low type, M type, or H high type; with shelf, option box, 19-inch rack, or water tank)
| Model | SH-642 |
|---|
La cámara Espec SH-642 ofrece un control preciso de temperatura y humedad para pruebas ambientales fiables. Con gran capacidad y diseño robusto, garantiza una validación precisa del producto en pruebas prolongadas. Diseñada para industrias exigentes, la SH-642 cumple con las normas internacionales y asegura estabilidad a largo plazo.
Ideal para muestras más grandes, la cámara admite procesos de validación extensos con un rendimiento confiable. Su construcción resistente garantiza resultados consistentes incluso bajo un uso intensivo.
Testwall puede suministrar la cámara Espec SH-642 usada, completamente probada. Con soporte experto y entrega global, Testwall asegura instrumentos de alto rendimiento con una fiabilidad y calidad de servicio inigualables. Contáctenos directamente si necesita calibración o reparación de la Espec SH-642.
