Exfo
Exfo FOT-932
FTTx Return/Loss Tester
800 nm a 1700 nm Rango de longitud de onda
-73 dBm a +3 dBm Rango de potencia óptica
±0,2 dB Incertidumbre de calibración
0,01 dB Resolución de medición
InGaAs Tipo de detector
| Atributo | Valor |
|---|---|
| Rango de longitud de onda | 800 nm a 1700 nm |
| Rango de potencia óptica | -73 dBm a +3 dBm |
| Incertidumbre de calibración | ±0,2 dB |
| Resolución de medición | 0,01 dB |
| Tipo de detector | InGaAs |
| Interfaz de conector | Universal (adaptadores intercambiables FC, SC, ST, LC) |
| Alimentación | Batería recargable de iones de litio |
| Autonomía de la batería | Hasta 200 horas de operación continua |
| Temperatura de operación | -10 °C a +50 °C |
| Normas de cumplimiento | IEC 61010-1, IEC 61326-1 |
Exfo FOT-932 Options:
- FOT-932 - FOT-932 - Ge detector, dual-wavelength 1310/1550 nm
- FOT-932 - FOT-932-4 - Ge detector, triple-wavelength 1310/1550/1625 nm
- FOT-932 - FOT-932-5 - Ge detector, triple-wavelength 1310/1490/1550 nm
- FOT-932 - FOT-932X - GeX detector, dual-wavelength 1310/1550 nm
- FOT-932 - FOT-932X-4 - GeX detector, triple-wavelength 1310/1550/1625 nm
- FOT-932 - FOT-932X-5 - GeX detector, triple-wavelength 1310/1490/1550 nm
- FOT-932 - FOT-933 - InGaAs detector, dual-wavelength 1310/1550 nm
- FOT-932 - FOT-933-4 - InGaAs detector, triple-wavelength 1310/1550/1625 nm
- FOT-932 - FOT-933-5 - InGaAs detector, triple-wavelength 1310/1490/1550 nm
- FOT-932 - FOT-932-MM - Ge detector (with multimode second source only)
- FOT-932 - 00 - Without second source
- FOT-932 - 12C - 850/1300 nm LED 50/125 µm second source
- FOT-932 - 12D - 850/1300 nm LED 62.5/125 µm second source
- FOT-932 - 00 - Without talk set and VFL
- FOT-932 - VFL - With visual fault locator
- FOT-932 - VFT - With talk set and VFL (universal 2.5 mm connector)
- FOT-932 - EI-EUI-28 - UPC/DIN 47256 connector
- FOT-932 - EI-EUI-76 - UPC/HMS-10/AG connector
- FOT-932 - EI-EUI-89 - UPC/FC narrow key connector
- FOT-932 - EI-EUI-90 - UPC/ST connector
- FOT-932 - EI-EUI-91 - UPC/SC connector
- FOT-932 - EI-EUI-95 - UPC/E-2000 connector
- FOT-932 - EA-EUI-28 - APC/DIN 47256 connector
- FOT-932 - EA-EUI-89 - APC/FC narrow key connector
- FOT-932 - EA-EUI-91 - APC/SC connector
- FOT-932 - EA-EUI-95 - APC/E-2000 connector
- FOT-932 - 00 - Without probe
- FOT-932 - FP4S - Inspection probe (400x)
- FOT-932 - FP4D - Inspection probe (200x/400x)
| Model | FOT-932 |
|---|
The FOT-932 MaxTester provides fully automated loss test results in 10 seconds for up to three wavelengths, as well as automatic ORL and fiber-length measurement. It comes with a large, high-resolution color display and nine hours autonomy -- all this and more in an ergonomic, eye-catching handheld package built for today's fiber-optic testing requirements. This unit easily and efficiently provides complete, high-quality test documentation. Its data logging and management features help users quickly access and download test results to any PC through the RS-232 port for in-depth analysis and first-class report generation.
