Exfo
Exfo FTB-5503
PMD Analyzer Module
1260 nm – 1650 nm Rango de longitud de onda
hasta 45 dB Rango dinámico
0,8 m Resolución de punto muerto de evento
4 m Resolución de punto muerto de atenuación
±0,05 dB/dB Precisión de pérdida
| Atributo | Valor |
|---|---|
| Rango de longitud de onda | 1260 nm – 1650 nm |
| Rango dinámico | hasta 45 dB |
| Resolución de punto muerto de evento | 0,8 m |
| Resolución de punto muerto de atenuación | 4 m |
| Precisión de pérdida | ±0,05 dB/dB |
| Precisión de distancia | ±1 m ±3 × 10⁻⁵ × distancia |
| Tipo de fibra compatible | Monomodo (SMF) y multimodo (MMF) |
| Interfaz de conector | Conector universal intercambiable (SC, LC, FC, ST) |
| Plataforma compatible | EXFO FTB-500 / FTB-200 |
| Aplicación principal | Pruebas OTDR para redes de fibra óptica de alta densidad y FTTx |
Exfo FTB-5503 Options:
- FTB-5503 - ER - Extended range option (analysis range 0.05 to 200 ps)
- FTB-5503 - 89 - FC/UPC connector type
- FTB-5503 - 90 - ST/UPC connector type
| Model | FTB-5503 |
|---|
Housed in the FTB-400 portable platform, the FTB-5503 Polarization Mode Dispersion Analyzer uses a patented approach to measuring PMD of installed links -- amplified or not -- as specified by the TIA's new FOTP-124A standard and according to the generalized interferometric approach (GINTY). It is the only PMD unit in the world to test through EDFAs, which is made possible thanks to the mathematical subtraction of the autocorrelation peak in the interferogram. This also enables the use of any source shape. For the first time, a PMD of zero can be measured as such. PMD is now measured precisely, no more mere assumptions.
