Fluke 700P02
| Atributo | Valor |
|---|---|
| Rango de presión | 0 a 0,35 bar (0 a 5 psi) |
| Tipo de presión | Presión manométrica |
| Precisión | ±0,05% del fondo de escala |
| Señal de salida | 4 a 20 mA |
| Tensión de alimentación | 12 a 45 V CC |
| Temperatura de funcionamiento | -10 °C a 50 °C |
| Temperatura de almacenamiento | -20 °C a 70 °C |
| Conexión de proceso | 1/4 NPT macho |
| Materiales en contacto con el fluido | Acero inoxidable 316L |
| Presión máxima de trabajo | 2 veces el fondo de escala |
Fluke 700P02 Options:
- 700P02 - FLUKE-700P01 - Differential Pressure Module, 10 in. H2O / 0.01 range, Dry/Dry media, 316 SS fittings
- 700P02 - FLUKE-700P02 - Differential Pressure Module, 1 psi / 0.0001 range, Dry/Dry media, 316 SS fittings
- 700P02 - FLUKE-700P22 - Differential Pressure Module, 1 psi / 0.0001 range, 316 SS/Dry media, 316 SS fittings
- 700P02 - FLUKE-700P03 - Differential Pressure Module, 5 psi / 0.0001 range, Dry/Dry media, 316 SS fittings
- 700P02 - FLUKE-700P23 - Differential Pressure Module, 5 psi / 0.0001 range, 316 SS/Dry media, 316 SS fittings
- 700P02 - FLUKE-700P04 - Differential Pressure Module, 15 psi / 0.001 range, Dry/Dry media, 316 SS fittings
- 700P02 - FLUKE-700P24 - Differential Pressure Module, 15 psi / 0.001 range, 316 SS/Dry media, 316 SS fittings
- 700P02 - FLUKE-700P05 - Gage Pressure Module, 30 psi / 0.001 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700P06 - Gage Pressure Module, 100 psi / 0.01 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700P07 - Gage Pressure Module, 500 psi / 0.01 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700P08 - Gage Pressure Module, 1000 psi / 0.1 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700P09 - Gage Pressure Module, 1500 psi / 0.1 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700PA3 - Absolute Pressure Module, 5 psi / 0.0001 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700PA4 - Absolute Pressure Module, 15 psi / 0.001 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700PA5 - Absolute Pressure Module, 30 psi / 0.001 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700PA6 - Absolute Pressure Module, 100 psi / 0.01 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700PV3 - Vacuum Pressure Module, -5 psi / 0.0001 range, 316 SS/Dry media, 316 SS fittings
- 700P02 - FLUKE-700PV4 - Vacuum Pressure Module, -15 psi / 0.001 range, 316 SS/Dry media, 316 SS fittings
- 700P02 - FLUKE-700PD2 - Dual Pressure Module, 1 psi / 0.0001 range, 316 SS/Dry media, 316 SS fittings
- 700P02 - FLUKE-700PD3 - Dual Pressure Module, 5 psi / 0.0001 range, 316 SS/Dry media, 316 SS fittings
- 700P02 - FLUKE-700PD4 - Dual Pressure Module, 15 psi / 0.001 range, 316 SS/Dry media, 316 SS fittings
- 700P02 - FLUKE-700PD5 - Dual Pressure Module, -15/30 psi / 0.001 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700PD6 - Dual Pressure Module, -15/100 psi / 0.01 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700PD7 - Dual Pressure Module, -15/200 psi / 0.01 range, 316 SS media, 316 SS fittings
- 700P02 - FLUKE-700P29 - High Pressure Module, 3000 psi / 0.1 range, C276 media, C276 fittings
- 700P02 - FLUKE-700P30 - High Pressure Module, 5000 psi / 0.1 range, C276 media, C276 fittings
- 700P02 - FLUKE-700P31 - High Pressure Module, 10000 psi / 1 range, C276 media, C276 fittings
- 700P02 - FLUKE-700PCK - Pressure Calibration Kit; includes power supply, interface adapter, cables, and 700PC Pressure Module Calibration software
- 700P02 - FLUKE-700PMP - Hand operated Pressure Pump, provides pressures up to approximately 150 psi (1000 kPa)
| Model | 700P02 |
|---|
Fluke 700P02 Differential Pressure Module
The Fluke 700P02 Differential Pressure Module allows to measure pressure with the Fluke 700 Series Process Calibrators. It displays pressure readings in any of 10 diffe pressure units specified in the calibrator setup. This differential pressure module has two pressure fittings and measures the difference between the applied pressure on the high fitting versus the low fitting. Fluke 700P01 Differential Pressure Module functions like a gauge module when the low fitting is open.
Fluke 700P02 Differential Pressure Module features internal temperature compensation from 0 °C to 50 °C for full-accuracy performance. The pressure module measures pressure using an internal microprocessor. It receives operating power from and sends digital information to the calibrator. This module can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit, a PC, and a precision pressure source. Rugged urethane molded case of Fluke 700P02 protects the module from rough handling and harsh conditions.
Specifications for the Fluke 700P02 Differential Pressure Module Include:
| Resolution | 0.0001 / 0.7 |
| Measurement range | 1 psi / 6900 Pa |
| Reference Uncertainty (23 ± 3 °C) | 0.15 |
| Total Uncertainty 1 year | 0.3 |
