Fluke 700P03
| Atributo | Valor |
|---|---|
| Rango de presión | 0 a 1 bar (0 a 15 psi) |
| Tipo de presión | Presión manométrica |
| Precisión | ±0,05% del fondo de escala |
| Señal de salida | 4 a 20 mA |
| Tensión de alimentación | 9 a 28 V CC |
| Temperatura de funcionamiento | -20 °C a 85 °C |
| Conexión de proceso | 1/4 NPT macho |
| Conector eléctrico | DIN 43650 |
| Presión máxima de sobrecarga | 2 veces la presión nominal |
| Compatibilidad | Compatible con los calibradores de presión Fluke serie 700 |
| Model | 700P03 |
|---|
Fluke 700P03 Differential Pressure Module
The Fluke 700P03 Differential Pressure Module allows to measure pressure with the Fluke 700 Series Process Calibrators. It displays pressure readings in any of 10 diffe pressure units specified in the calibrator setup. This differential pressure module has two pressure fittings and measures the difference between the applied pressure on the high fitting versus the low fitting. Fluke 700P03 Differential Pressure Module functions like a gauge module when the low fitting is open.
Fluke 700P03 Differential Pressure Module features internal temperature compensation from 0 °C to 50 °C for full-accuracy performance. The pressure module measures pressure using an internal microprocessor. It receives operating power from and sends digital information to the calibrator. This module can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit, a PC, and a precision pressure source. Rugged urethane molded case of Fluke 700P03 protects the module from rough handling and harsh conditions.
Specifications for the Fluke 700P03 Differential Pressure Module Include:
| Resolution | 0.0001 / 0.001 |
| Measurement range | 5 psi / 34 kPa |
| Reference Uncertainty (23 ± 3 °C) | 0.050% |
| Total Uncertainty 1 year | 0.100 |
