Hameg
Hameg HMP4030 Power Supply
3 Número de canales
32 V por canal Tensión de salida máxima
10 A (canal 1 y 2), 5 A (canal 3) Corriente de salida máxima
188 W Potencia total máxima
1 mV Resolución de tensión
| Atributo | Valor |
|---|---|
| Número de canales | 3 |
| Tensión de salida máxima | 32 V por canal |
| Corriente de salida máxima | 10 A (canal 1 y 2), 5 A (canal 3) |
| Potencia total máxima | 188 W |
| Resolución de tensión | 1 mV |
| Resolución de corriente | 1 mA |
| Interfaces de comunicación | USB, RS-232, Ethernet (opcional GPIB) |
| Pantalla | Pantalla gráfica LCD retroiluminada |
| Modos de operación | Tensión constante (CV) y corriente constante (CC) |
| Tensión de alimentación | 115/230 V AC, 50/60 Hz |
Hameg HMP4030 Power Supply Options:
- HMP4030 - HO730 - Dual-Interface Ethernet/USB
- HMP4030 - HO740 - Interface IEEE-488 (GPIB), galvanically isolated
- HMP4030 - HZ10S - 5 x silicone test lead (measurement connection in black)
- HMP4030 - HZ10R - 5 x silicone test lead (measurement connection in red)
- HMP4030 - HZ10B - 5 x silicone test lead (measurement connection in blue)
- HMP4030 - HZ13 - Interface cable (USB) 1.8m
- HMP4030 - HZ14 - Interface cable (serial) 1:1
- HMP4030 - HZ43 - 19" Rackmount Kit 3RU
- HMP4030 - HZ72 - GPIB-Cable 2m
- HMP4030 - HZP91 - 19" Rackmount Kit 4RU
| Model | HMP4030 |
|---|
The HMP4030 is a high-performance programmable power supply.
With advanced parallel and series operation offering: simultaneous switching on/off of active Channels via "Output" button, common voltage- and current control using tracking mode (individual channel linking), individual mapping of Channels which shall be affected by FuseLink overcurrent protection (switch-off) and all Channels galvanically isolated from each other and the protective earth.
Key Features
- Intelligent power management
- Low residual ripple: < 150 ?V (RMS)
- Advanced parallel and serial operation via V/I tracking
- EasyArb function for user-definable V/I characteristics
- FuseLink: individual channel combination of electronic fuses
- User-adjustable overvoltage protection (OVP) for all outputs
- USB/RS-232 interface, optionally Ethernet/USB or IEEE 488 (GPIB)
- Galvanically isolated, earth-free and short-circuit-protected output channels
