Hioki
Hioki MR8880-20
Memory HiCorder, 4 ch., 600 V AC/DC
20 canales Número de canales
10 ms/canal (100 muestras/segundo) Frecuencia de muestreo
Tensión, termopar, resistencia de temperatura (PT100) Tipos de entrada
±100 mV a ±100 V (6 rangos) Rango de medición de tensión
±0,1% de la lectura Precisión básica
| Atributo | Valor |
|---|---|
| Número de canales | 20 canales |
| Frecuencia de muestreo | 10 ms/canal (100 muestras/segundo) |
| Tipos de entrada | Tensión, termopar, resistencia de temperatura (PT100) |
| Rango de medición de tensión | ±100 mV a ±100 V (6 rangos) |
| Precisión básica | ±0,1% de la lectura |
| Capacidad de almacenamiento interno | 128 MB de memoria interna |
| Interfaz de comunicación | USB, LAN (Ethernet 100BASE-TX) |
| Pantalla | Pantalla LCD a color de 5,7 pulgadas |
| Temperatura de funcionamiento | 0 °C a 50 °C, humedad relativa de hasta 80% sin condensación |
| Dimensiones y peso | 210 mm × 153 mm × 51 mm, aprox. 1,3 kg |
Hioki MR8880-20 Options:
- MR8880-20 - MR9000 - Printer Unit, printing width 100 mm, used together with the MR8880-20 main body, includes 1 roll of recording paper
- MR8880-20 - 9234 - Recording Paper, 112 mm × 18 m, roll type, 10 rolls/set
- MR8880-20 - Z1000 - Battery Pack, NiMH, charges while installed in the main unit
- MR8880-20 - Z1002 - AC Adapter, for main unit, 100 to 240 V AC
- MR8880-20 - C1003 - Carrying Case, includes compartment for options, soft case type
- MR8880-20 - L9217 - Connection Cord, insulated BNC connectors at both ends, for signal output, 1.6 m length
- MR8880-20 - 9320-01 - Logic Probe, 4-channel type, for voltage/contact signal ON/OFF detection, response pulse width 500 ns or more, miniature terminal type
- MR8880-20 - MR9321-01 - Logic Probe, 4 isolated channels, ON/OFF detection of AC/DC voltage, miniature terminal type
- MR8880-20 - P9000-01 - Differential Probe, waveform only, up to 1 kV AC/DC, bandwidth up to 100 kHz
- MR8880-20 - P9000-02 - Differential Probe, waveform/RMS value switchable, up to 1 kV AC/DC, bandwidth up to 100 kHz
- MR8880-20 - Z1008 - AC Adapter, 100 to 240 V AC (for P9000)
- MR8880-20 - 9322 - Differential Probe, for up to 1 kV AC or 2 kV DC, frequency bandwidth up to 10 MHz
- MR8880-20 - 9418-15 - AC Adapter, 100 to 240 V AC (for Differential Probe 9322)
- MR8880-20 - 9728 - PC Card 512M, 512 MB capacity (includes PC card adapter)
- MR8880-20 - 9729 - PC Card 1G, 1 GB capacity (includes PC card adapter)
- MR8880-20 - 9830 - PC Card 2G, 2 GB capacity (includes PC card adapter)
- MR8880-20 - Z4006 - USB Drive, 16 GB, long-life, high-reliability SLC Flash Memory
- MR8880-20 - 9335 - Wave Processor software, distribution media: one CD-R, Windows 10/8/7 (32/64-bit)
- MR8880-20 - L9197 - Connection Cord, φ 5.0 mm dia., cable allowing for up to 600 V input, 1.8 m length, detachable large alligator clips bundled
- MR8880-20 - L9198 - Connection Cord, φ 5.0 mm dia., cable allowing for up to 300 V input, 1.7 m length, small alligator clip
- MR8880-20 - L9790 - Connection Cord, flexible φ 4.1 mm thin dia., cable allowing for up to 600 V input, 1.8 m length (end clip sold separately)
- MR8880-20 - L9790-01 - Alligator Clip, red/black set, attaches to the ends of the cables L9790
- MR8880-20 - 9790-02 - Grabber Clip, red/black set, attaches to the ends of the cables L9790
- MR8880-20 - 9790-03 - Contact Pin, red/black set, attaches to the ends of the cables L9790
- MR8880-20 - 9243 - Grabber Clip, attaches to the tip of the banana plug cable, CAT III 1000 V, 196 mm length
- MR8880-20 - L9095 - Output Cord, connect to BNC terminal, 1.5 m length
- MR8880-20 - 3283 - Clamp On Leak HiTester, 10 mA range/10 μA resolution to 200 A range, with monitor/analog output 1 V f.s.
- MR8880-20 - 9018-50 - Clamp On Probe, good phase characteristics, frequency characteristics 40 Hz to 3 kHz, 10 to 500 A AC range, output 0.2 V AC f.s.
- MR8880-20 - 9132-50 - Clamp On Probe, frequency characteristics 40 Hz to 1 kHz, 20 to 1000 A AC range, output 0.2 V AC f.s.
- MR8880-20 - CT9667-01 - AC Flexible Current Sensor, 10 Hz to 20 kHz, 5000 A/500 A AC, 500 mV/f.s. output, φ 100 mm loop diameter
- MR8880-20 - CT9667-02 - AC Flexible Current Sensor, 10 Hz to 20 kHz, 5000 A/500 A AC, 500 mV/f.s. output, φ 180 mm loop diameter
- MR8880-20 - CT9667-03 - AC Flexible Current Sensor, 10 Hz to 20 kHz, 5000 A/500 A AC, 500 mV/f.s. output, φ 254 mm loop diameter
- MR8880-20 - CT7631 - AC/DC Current Sensor, DC, 1 Hz to 10 kHz (-3dB), 100 A, 1 mV/A output
- MR8880-20 - CT7731 - AC/DC Current Sensor (Auto zero), DC, 1 Hz to 10 kHz (-3dB), 100 A, 1 mV/A output
- MR8880-20 - CT7636 - AC/DC Current Sensor, DC, 1 Hz to 10 kHz (-3dB), 600 A, 1 mV/A output
- MR8880-20 - CT7736 - AC/DC Current Sensor (Auto zero), DC, 1 Hz to 10 kHz (-3dB), 600 A, 1 mV/A output
- MR8880-20 - CT7642 - AC/DC Current Sensor, DC, 1 Hz to 10 kHz (5 kHz), 2000 A, 1 mV/A output
- MR8880-20 - CT7742 - AC/DC Current Sensor (Auto zero), DC, 1 Hz to 10 kHz (5 kHz), 2000 A, 1 mV/A output
- MR8880-20 - CM7290 - Display Unit, provides measurement, display, and output functionality when used with CT7000 series
- MR8880-20 - CM7291 - Display Unit, with built-in Bluetooth wireless technology
- MR8880-20 - CT6875 - AC/DC Current Sensor, 2 MHz bandwidth, 500 A, high-precision pull-through type
- MR8880-20 - CT6844-05 - AC/DC Current Probe, 200 kHz bandwidth, 500 A
- MR8880-20 - CT6845-05 - AC/DC Current Probe, 100 kHz bandwidth, 500 A
- MR8880-20 - CT6846-05 - AC/DC Current Probe, 20 kHz bandwidth, 1000 A
- MR8880-20 - CT9555 - Sensor Unit, 1ch, with waveform output (power supply for current sensors)
- MR8880-20 - CT9900 - Conversion Cable, converts PL23 (10-pin) terminal to ME15W (12-pin) terminal
- MR8880-20 - SP3000-01 - Non-Contact AC Voltage Probe, 5 Vrms rated, 10 Hz to 100 kHz bandwidth
- MR8880-20 - SP3000 - Non-Contact AC Voltage Probe, sold individually
- MR8880-20 - SP9001 - AC Voltage Probe, sold individually
- MR8880-20 - 9445-02 - AC Adapter, 100 to 240 V AC
- MR8880-20 - 9445-03 - AC Adapter, for EU, 100 to 240 V AC
| Model | MR8880-20 |
|---|
El Hioki MR8880-20 Memory HiCorder es un registrador de adquisición de datos versátil con aislamiento CAT III 600 V, diseñado para entornos exigentes. Admite mediciones directas de hasta 600V AC/DC sin necesidad de sonda diferencial. Con 4 canales completamente aislados, permite registrar simultáneamente una línea trifásica y un canal adicional.
Su construcción robusta, velocidad de medición rápida y amplio rango de temperatura lo convierten en una herramienta confiable para caídas de tensión, cortes eléctricos y sistemas complejos.
Testwall puede suministrar el Hioki MR8880-20 Memory HiCorder usado, completamente probado. Con soporte experto y entrega global, Testwall asegura instrumentos de alto rendimiento y máxima fiabilidad. Contáctenos para calibración o reparación del Hioki MR8880-20 Memory HiCorder.
