Hipotronics 880PL-10MA
| Atributo | Valor |
|---|---|
| Voltaje de salida máximo | 880 V CC |
| Corriente de salida máxima | 10 mA |
| Tipo de corriente de prueba | Corriente continua (CC) |
| Potencia nominal | 8,8 W |
| Regulación de voltaje | ±1% |
| Medición de corriente de fuga | Incorporada con resolución de microamperios |
| Temporizador de prueba | Temporizador digital ajustable integrado |
| Indicación de fallo | Alarma audible y visual con disparo automático |
| Alimentación eléctrica de entrada | 115/230 V CA, 50/60 Hz |
| Normas de cumplimiento | ASTM, IEC, UL y IEEE |
Hipotronics 880PL-10MA Options:
- 880PL-10MA - HHDA13-280 - 120kV rated grounding stick
- 880PL-10MA - HH-SAFE - Safety strobe light with magnetic base
- 880PL-10MA - HH-FS - Foot operated interlock switch
- 880PL-10MA - EXT-WARN - External Warning Lamp
- 880PL-10MA - HH-HS - Hand operated interlock switch
- 880PL-10MA - WARRANTY-2YR - Warranty Extension to 2 years
- 880PL-10MA - WARRANTY-3YR - Warranty Extension to 3 years
| Model | 880PL-10MA |
|---|
RENT Hiptronics 880PL-10MA (call for availability)
The Hiptoronics 880PL-10mA DC hipot tester is an economical solution to DC field testing of cables, terminations, motors, generators and other electrical apparatus. The Hipotronics 880PL10-MA 80kV and is self-contained in a single, rugged and durable enclosure, which is complete from input line cord to high voltage output cable. Cable storage space is conveniently located inside.
The 880PL testers features accurate kV meter readings regardless of load current. Accurate voltage and cur measurements are assured via voltage readings that are taken directly at the output of the high voltage transformer and cur measurements are taken in the return leg. Safe discharging of both the test object and the high voltage transformer occur whenever the high voltage is turned off. Output power is provided by means of a full-wave voltage doubling rectifier circuit with silicon rectifiers.
Features of the Hipotronics 880PL-10MA include:
- Rugged, portable single-piece construction
- Shielded output cable
- Full-wave voltage doubling rectifier circuit
- Zero start interlock and guard circuit
- Internal discharge solenoid
- Meter accuracy ± 2% full scale
- 10 mA cur rating for cable charging
- External interlock provisions
- Three range voltmeter
- Four range cur meter
- No internal leakage at full load
- Instantaneous overload relay
- Surge-limiting resistors in HV output
Benefits of the Hipotronics 880PL include:
- Ideal for field testing €“ compact, lightweight and rugged makes it suitable for field orientated applications
- Operator Safety €“ the power supply and test object are automatically grounded when high voltage is turned off and there is no exposed high voltage
- Simple to Use - a minimal amount of setup time and a simple control panel allows simple testing every time
- Accurate Leakage Cur Measurement - while guard circuit eliminates stray leakage currents
Technical Specifications for the Hipotronics 880PL-10MA:
- Input Voltage: 120V, 50/60 Hz
- Output Voltage: 0-80 KV
- Output Current: 10 mA
- Polarity: Negative Output, Possitive Ground
- Metering: + 2% full scale accuracy
- Ripple: 0.5% per mA with rated resistance
Hipotronics 880PL-10MA
