IMADA ZTA-44 Digital Force Gauge
The Imada ZTA-44 Digital Force Gauge designed for measuring the pushing and pulling force up to a capacity of 44 lbf or 20 kgf or 200 N. It is an advanced tool with high speed sampling, ELD display and USB output. It's intuitive menus make it easy to select units, reverse the display and program high/low setpoints. A large, bright Electroluminescent display (ELD) shows force value, unit of measure, and peak, and can be configured with additional user-selectable data including memory data, +NG count, high/low setpoints, 1st and 2nd peaks, displacement value (using a test stand with FA?option), etc.
Imada ZTA-44 Digital Force Gauge is capable of the highly accurate measurements required in quality testing to determine the strength or functionality of a part or product. Imada ZTA-44 features color-coded LED indicators alert the user to Go/NoGo conditions. Orange lights for less than low setpoint, green lights between high and low, and red for over the high. It can process and transmit 2,000 actual data per second, not just the peak from a high sampling rate. ZTA-44 can save continuous captured data at 100 data/second to flash drives. Imada ZTA-44 Digital Force Gauge features a variety of data output options including USB, RS-232C, Digimatic and Analog outputs, enabling to transfer data to a PC or data logger for further analysis or record keeping.
Specifications for the IMADA ZTA-44 Digital Force Gauge Include:
| Capacity | 44.00 lbf / 20.00 kgf / 200.0 N |
| Resolution | 0.01 lbf / 0.01 kgf / 0.1 N |
| Accuracy | ± 0.2% F.S., ± 1 LSD |
| Overload Capacity | 200% of F.S. |
