Keithley
Keithley 4200-SMU
Medium Power Source Measure Unit (SMU)
±210 V Rango de tensión de salida
±100 mA Rango de corriente de salida
5 µV Resolución de tensión mínima
0,5 fA Resolución de corriente mínima
2,2 W Potencia máxima de salida
| Atributo | Valor |
|---|---|
| Rango de tensión de salida | ±210 V |
| Rango de corriente de salida | ±100 mA |
| Resolución de tensión mínima | 5 µV |
| Resolución de corriente mínima | 0,5 fA |
| Potencia máxima de salida | 2,2 W |
| Modos de operación | Fuente de tensión/medida de corriente (FVMI), Fuente de corriente/medida de tensión (FIMV) |
| Exactitud básica de tensión | 0,02% |
| Exactitud básica de corriente | 0,03% |
| Compatibilidad | Compatible con el sistema de caracterización de semiconductores Keithley 4200-SCS |
| Interfaz de conexión | Módulo de expansión para instalación en chasis del sistema 4200-SCS |
Keithley 4200-SMU Options:
- 4200-SMU - 4210-SMU - High-Power Source-Measure Unit for 4200-SCS. 1A to 100fA, 200V to 1µV, 20 Watt
- 4200-SMU - 4200-PA - Remote PreAmp Option for 4200-SMU and 4210-SMU, extends SMU to 0.1fA resolution
- 4200-SMU - 4200-CAL - 4200-SCS Return Calibration Service
- 4200-SMU - 4200-3Y-CAL - 4200-SCS 3 Year Return Calibration Service
- 4200-SMU - 4200-5Y-CAL - 4200-SCS 5 Year Return Calibration Service
- 4200-SMU - 4200-REPAIR - 4200-SCS Repair Service
- 4200-SMU - 4200-3Y-REPAIR - 4200-SCS 3 Year Hardware Warranty Extension
- 4200-SMU - 4200-5Y-REPAIR - 4200-SCS 5 Year Hardware Warranty Extension
- 4200-SMU - 4200-UPGRADE - 4200-SCS Hardware Upgrade Service
- 4200-SMU - 4200-CRT - 17˝ SVGA Color Monitor
- 4200-SMU - 4200-MOUSE - Microsoft Ambidextrous 2 Button Mouse
- 4200-SMU - 4200-MAG-BASE - Magnetic base for mounting 4200-PA on a prober platen
- 4200-SMU - 4200-VAC-BASE - Vacuum base for mounting 4200-PA on a prober platen
- 4200-SMU - 4200-TMB - Triaxial mounting bracket for mounting 4200-PA on a triaxial mounting panel
- 4200-SMU - 4200-MAN - Printed Manual set for 4200-SCS
- 4200-SMU - 4200-CART - Roll-around cart for 4200-SCS
- 4200-SMU - 8006 - Component Test Fixture
- 4200-SMU - 8007 - Semiconductor Test Fixture
- 4200-SMU - 4200-590 - Model 590/100k/1M C-V Analyzer with IEEE-488 Interface, 1m IEEE cable, 2ea BNC-Triaxial Adapters
- 4200-SMU - 5909 - Calibration Sources for Model 590 C-V Analyzer
- 4200-SMU - 4200-UL-LS-12 - Ultra-Low Current/Local Sense Switch Matrix Configuration, 12 pins
- 4200-SMU - 4200-UL-LS-24 - Ultra-Low Current/Local Sense Switch Matrix Configuration, 24 pins
- 4200-SMU - 4200-UL-LS-36 - Ultra-Low Current/Local Sense Switch Matrix Configuration, 36 pins
- 4200-SMU - 4200-UL-LS-48 - Ultra-Low Current/Local Sense Switch Matrix Configuration, 48 pins
- 4200-SMU - 4200-UL-LS-60 - Ultra-Low Current/Local Sense Switch Matrix Configuration, 60 pins
- 4200-SMU - 4200-UL-LS-72 - Ultra-Low Current/Local Sense Switch Matrix Configuration, 72 pins
- 4200-SMU - 4200-UL-RS-6 - Ultra-Low Current/Remote Sense Switch Matrix Configuration, 6 pins
- 4200-SMU - 4200-UL-RS-12 - Ultra-Low Current/Remote Sense Switch Matrix Configuration, 12 pins
- 4200-SMU - 4200-UL-RS-18 - Ultra-Low Current/Remote Sense Switch Matrix Configuration, 18 pins
- 4200-SMU - 4200-UL-RS-24 - Ultra-Low Current/Remote Sense Switch Matrix Configuration, 24 pins
- 4200-SMU - 4200-UL-RS-30 - Ultra-Low Current/Remote Sense Switch Matrix Configuration, 30 pins
- 4200-SMU - 4200-LC-RS-XX - Low Current/Remote Sense Switch Matrix Configuration
- 4200-SMU - 4200-GP-RS-12 - General-Purpose/Remote Sense Switch Matrix Configuration, 12 pins
- 4200-SMU - 4200-GP-RS-24 - General-Purpose/Remote Sense Switch Matrix Configuration, 24 pins
- 4200-SMU - 4200-GP-RS-36 - General-Purpose/Remote Sense Switch Matrix Configuration, 36 pins
- 4200-SMU - 4200-GP-RS-48 - General-Purpose/Remote Sense Switch Matrix Configuration, 48 pins
- 4200-SMU - 4200-GP-RS-60 - General-Purpose/Remote Sense Switch Matrix Configuration, 60 pins
- 4200-SMU - 4200-GP-RS-72 - General-Purpose/Remote Sense Switch Matrix Configuration, 72 pins
- 4200-SMU - 4200-CAB-20UX - 20U Cabinet (35 in.)
- 4200-SMU - 4200-CAB-25UX - 25U Cabinet (44 in.)
- 4200-SMU - 4200-CAB-34UX - 34U Cabinet (60 in.)
- 4200-SMU - 4200-RM - Slide Rack Mounting Kit for 4200-SCS/F and 4200-SCS/C
- 4200-SMU - 4200-CRT-RM - Fixed Rack Mounting Kit for 4200-CRT
- 4200-SMU - 4200-KEY-RM - Slide Rack Mounting Kit for standard keyboard and pointing device
- 4200-SMU - 2288-1G - Model 590 Rack Mount Kit
- 4200-SMU - 4200-RPC-0.3 - Remote PreAmp Cable, 0.3m (for use inside prober shield)
- 4200-SMU - 4200-RPC-2 - Remote PreAmp Cable, 2m (for remote location of 4200-PA)
- 4200-SMU - 4200-RPC-3 - Remote PreAmp Cable, 3m (for remote location of 4200-PA)
- 4200-SMU - 4200-RPC-6 - Remote PreAmp Cable, 6m (for remote location of 4200-PA)
- 4200-SMU - 4200-TRX-0.3 - Ultra Low Noise PreAmp Triax Cable, 0.3m (Triax-Triax)
- 4200-SMU - 4200-TRX-1 - Ultra Low Noise PreAmp Triax Cable, 1m (Triax-Triax)
- 4200-SMU - 4200-TRX-2 - Ultra Low Noise PreAmp Triax Cable, 2m (Triax-Triax)
- 4200-SMU - 4200-TRX-3 - Ultra Low Noise PreAmp Triax Cable, 3m (Triax-Triax)
- 4200-SMU - 4200-MTRX-1 - Ultra Low Noise SMU Triax Cable, 1m (Mini Triax-Triax)
- 4200-SMU - 4200-MTRX-2 - Ultra Low Noise SMU Triax Cable, 2m (Mini Triax-Triax)
- 4200-SMU - 4200-MTRX-3 - Ultra Low Noise SMU Triax Cable, 3m (Mini Triax-Triax)
- 4200-SMU - 236-ILC-3 - Interlock Cable, 3m
- 4200-SMU - 7007-1 - Shielded IEEE-488 Cable (1m)
- 4200-SMU - 7007-2 - Shielded IEEE-488 Cable (2m)
- 4200-SMU - 7078-TRX-BNC - Coaxial connector for connecting coax instruments to a triax matrix
| Model | 4200-SMU |
|---|
El Keithley 4200-SMU combina mediciones precisas con personalización avanzada, con extracción de parámetros en tiempo real, vídeos multilingües y salidas configurables para baja corriente.
Ideal para caracterizar materiales y pruebas de fiabilidad, con conmutación I-V/C-V, pruebas de fiabilidad y compatibilidad con sondas y controladores criogénicos.
Testwall puede suministrar el Keithley 4200-SMU usado, completamente probado. Con soporte experto y entrega global, Testwall garantiza instrumentos de alto rendimiento con fiabilidad y calidad de servicio. Contáctenos para calibración o reparación del Keithley 4200-SMU.
