Keysight (Agilent) 33320G
| Atributo | Valor |
|---|---|
| Rango de frecuencia | DC a 26,5 GHz |
| Impedancia | 50 Ohmios |
| Potencia máxima de entrada | 2 W (33 dBm) |
| Atenuación | 10 dB |
| Precisión de atenuación | ±1,0 dB |
| Conectores | APC-3.5 macho a APC-3.5 hembra |
| VSWR máximo | 1,35 |
| Temperatura de operación | 0 °C a +55 °C |
| Tipo de dispositivo | Atenuador de RF coaxial fijo |
| Normas de cumplimiento | MIL-A-3933 |
Keysight (Agilent) 33320G Options:
- 33320G - 008 - 8 inch (20.3 cm) ribbon cable with 14 pin flat pack male connector
- 33320G - 016 - 16 inch (40.6 cm) ribbon cable with 14 pin flat pack male connector
- 33320G - 011 - 5 volt solenoid operation
- 33320G - 890 - Calibration data: 4 GHz models: 20 frequencies
| Model | 33320G |
|---|
The Agilent 33320G dc to 4 GHz programmable step attenuator offers exceptional repeatability and reliability. The HP 33320G is the same as the HP 8494G. Attenuation is provided in 1 dB steps from 0 to 11 dB. Precision gold-plated leaf springs ensure long-life (over 5 million cycles) and very high attenuator repeatability (typically 0.01 dB). To improve measurement accuracy, NIST traceable data (SWR and attenuation) is available as Option 890. A maximum switching time of 20 ms (including contact settling) speeds automatic testing. Custom step attenuator/switch combinations are possible. The Agilent 11716A/B/C interconnect kits provide quick connection of Agilent 8494/5/6/7 1 dB and 10 dB step attenuators in series for greater dynamic range with 1 dB steps.
Features and specifications of the Agilent HP 33320G Attenuator include:
Superior RF Performance
- Frequency range: dc to 4 GHz
- Insertion loss at 0 dB: 0.6 dB + 0.09 dB/GHz
- Maximum SWR: 1.5
Repeatability and Life Span
- Repeatability life: 0.03 dB maximum
- 5 million cycles per section
Power Handling
- Maximum RF input power: 1 W (average), 100 W (peak)
Features
- Connector type: choice of Type-N female, SMA female, APC-7
- Programming connector: 12-pin Viking, optional 14-pin DIP
