Keysight (Agilent)
Keysight (Agilent) E3633A
Power Supply, 8V, 20A or 20V, 10A, 200W
20 V / 25 A ó 33 V / 15 A (modo dual) Voltaje de salida máximo
25 A (a 20 V) / 15 A (a 33 V) Corriente de salida máxima
200 W Potencia máxima de salida
≤ 0,01% + 2 mV Regulación de línea (voltaje)
≤ 0,01% + 2 mV Regulación de carga (voltaje)
| Atributo | Valor |
|---|---|
| Voltaje de salida máximo | 20 V / 25 A ó 33 V / 15 A (modo dual) |
| Corriente de salida máxima | 25 A (a 20 V) / 15 A (a 33 V) |
| Potencia máxima de salida | 200 W |
| Regulación de línea (voltaje) | ≤ 0,01% + 2 mV |
| Regulación de carga (voltaje) | ≤ 0,01% + 2 mV |
| Rizado y ruido (voltaje) | ≤ 0,35 mV rms / ≤ 2 mV pico a pico |
| Interfaces de comunicación | GPIB (IEEE-488) y RS-232 |
| Tensión de alimentación | 115 V / 230 V CA, 50/60 Hz |
| Dimensiones (An x Al x Pr) | 212,6 mm x 88,5 mm x 348,3 mm |
| Peso | 8,2 kg |
Keysight (Agilent) E3633A Options:
- E3633A - 0E3 - 230 Vac ± 10%
- E3633A - 0EM - 115 Vac ± 10%
- E3633A - 0E9 - 100 Vac ± 10%
- E3633A - 0L2 - Extra manual sets
- E3633A - 1CM - Rackmount kit
- E3633A - UK6 - Commercial calibration with test result data
| Model | E3633A |
|---|
KEYSIGHT E3633A (AGILENT)
The Agilent 200W, GPIB, single output E3633A is a high performance supply optimized for manual and basic automated testing; and, with a combination of benchtop capabilities and system features, it is designed to help improve measurement quality and reduce test time.
Specifications of the Keysight E3633A (Agilent) Power Supply include:
Output Ratings
- Range 1: 0 to 8 V, 20 A
- Range 2: 0 to 20 V, 10 A
Programming Accuracy at 25 °C ±5 °C
- Voltage: 0.05% + 10 mV
- Current: 0.2% +10 mA
Ripple & Noise (20 Hz to 20 MHz)
- Normal-mode voltage:
- Normal-mode current:
- Common-mode current:
Readback Accuracy at 25 °C ±5 °C
- Voltage: 0.05% + 5 mV
- Current: 0.15% + 5 mA
