Keysight (Agilent) N6702C
| Atributo | Valor |
|---|---|
| Número de salidas | Hasta 4 módulos de salida |
| Potencia total máxima | 400 W |
| Interfaz de comunicación | LAN (LXI), USB, GPIB |
| Tensión de entrada (CA) | 85 – 265 V CA, 47 – 63 Hz |
| Factor de forma | Montaje en rack, 2U (3,5 pulgadas de altura) |
| Compatibilidad de módulos | Compatible con módulos de la serie N6700 (N674xA, N675xA, N676xA) |
| Resolución de programación de voltaje | Hasta 1 mV (dependiendo del módulo instalado) |
| Resolución de programación de corriente | Hasta 0,1 mA (dependiendo del módulo instalado) |
| Funciones de medición | Medición de voltaje, corriente y potencia con registro de datos integrado |
| Cumplimiento normativo | LXI Class C, CE, CSA, IEC 61010-1 |
Keysight (Agilent) N6702C Options:
- N6702C - N6709C - Rack mount kit (required for rack mounting; standard rack mount hardware will not work)
- N6702C - N6708A - Filler panel kit (required when fewer than 4 modules installed; each kit contains 3 filler panels)
- N6702C - OL1 - Full documentation on CD-ROM and printed users guide
- N6702C - 900 - Power cord, United Kingdom, P/N 8120-1351
- N6702C - 901 - Power cord, Australia, New Zealand, P/N 8120-1369
- N6702C - 902 - Power cord, Europe, Korea, P/N 8120-1689
- N6702C - 903 - Power cord, USA, Canada, 120 V, P/N 8120-4383
- N6702C - 904 - Power cord, USA, Canada, 240 V, P/N 8120-0698
- N6702C - 906 - Power cord, Switzerland, P/N 8120-2104
- N6702C - 912 - Power cord, Denmark, P/N 8120-2956
- N6702C - 917 - Power cord, South Africa, India, P/N 8120-4211
- N6702C - 918 - Power cord, Japan, 100 V, P/N 8120-5342
- N6702C - 919 - Power cord, Israel, P/N 8120-6800
- N6702C - 920 - Power cord, Argentina, P/N 8120-6869
- N6702C - 921 - Power cord, Chile, P/N 8120-6980
- N6702C - 922 - Power cord, China, P/N 8120-8376
- N6702C - 927 - Power cord, Thailand, Brazil, P/N 8120-8871
- N6702C - 929 - Power cord, Japan, 200 V, P/N 8121-1392 (available only on model N6702C)
| Model | N6702C |
|---|
Keysight (Agilent) N6702C Power Supply Mainframe
The Keysight N6702C Low-Profile Modular Power System (MPS) is a 1U (rack unit) high, multiple-output programmable DC power supply or electronic load system that enables test system integrators to optimize performance, power and price to match test needs. The Keysight N6702C MPS gives test system designers the flexibility to mix and match from over 30 diffe DC power modules to create a 1- to 4-channel DC power system or electronic load system optimized to meet specific test requirements. The N6702C MPS comes standard with GPIB, USB 2.0, and 10/100 Base-T ethernet LAN interfaces.
For applications that require more than four DC power or electronic load modules to be sequenced, this output sequencing can be extended across multiple N6702C mainframes. The N6702C provides programmable voltage slew rate, so that you can easily control the speed at which the output slews from one voltage to another. To increase available voltage and power, similarly rated outputs can be operated directly in series on power supply modules. In addition to full control over its three standard interfaces, the N6702C has a full featured front panel to permit easy manual operation for test prototyping, debugging, and troubleshooting when used in an ATE system. You can have confidence that the N6702C is working properly because you can view the settings and actual output values on all four outputs at the same time.
Specifications for the Keysight (Agilent) N6702C Power Supply Mainframe Include:
