Keysight (Agilent) N7552A
| Atributo | Valor |
|---|---|
| Rango de Frecuencia | 100 MHz – 40 GHz |
| Número de Canales | 2 canales de señal de RF |
| Potencia de Salida Máxima | +20 dBm |
| Impedancia | 50 Ω |
| Tipo de Conector | 2.92 mm (K) macho |
| Atenuación de Aislamiento | ≥ 80 dB |
| Pérdida de Inserción | ≤ 6 dB |
| Interfaz de Control | GPIB, USB, LAN (LXI Clase C) |
| Tensión de Alimentación | 100 – 240 V CA, 50/60 Hz |
| Dimensiones (An × Al × Pr) | 212.6 mm × 88.6 mm × 348.3 mm |
Keysight (Agilent) N7552A Options:
- N7552A - 3FF - Both 3.5 mm connectors are female on module
- N7552A - 3MF - 1 female and 1 male connector on module, both 3.5 mm
- N7552A - 3MM - Both 3.5 mm connectors are male on module
- N7552A - NFF - Both Type-N, 50 Ω connectors are female on module
- N7552A - NMF - 1 female and 1 male connector on module, both Type-N, 50 Ω
- N7552A - NMM - Both Type-N, 50 Ω connectors are male on module
- N7552A - 150 - Plastic storage box
- N7550X-151 - 3.5 or 2.92 mm torque wrench
- N7550X-152 - Type-N torque wrench
| Model | N7552A |
|---|
Keysight (Agilent) N7552A Electronic Calibration Module
The N7552A is part of Keysight's family of value-line electronic calibration (ECal) modules that makes calibration of vector network analyzers fast, easy and accurate. Cut your calibration down to half the time it normally takes using a traditional mechanical cal kit. Simply connect it to your instrument and the firmware does the rest. The N7552A supports Keysight's , PNA-X, PNA, ENA, and PXI vector network analyzers and FieldFox handheld analyzers. The N7552A is a 2-port ECal module that supports 3.5 mm connectors or Type N connectors. he firmware installed on the instrument is used to control the calibration module, making it a fully integrated solution. The calibration code on the instrument communicates via a USB 2.0 micro-interface and simplifies the calibration to a single connection for a full two-port calibrated measurement.
Specifications for the Keysight (Agilent) N7552A Electronic Calibration Module Include:
| Frequency | DC to 9 GHz |
| Ports | 2 |
| Connector Type | 3.5mm, Type N |
