Keysight (Agilent)
Keysight (Agilent) N8732A
10V 330A 3300W DC Power Supply
20 V Tensión de salida
50 A Corriente de salida máxima
1000 W Potencia de salida máxima
208 / 400 / 480 V CA (trifásico) Tensión de entrada (CA)
Montaje en bastidor 1U (2U de altura) Factor de forma
| Atributo | Valor |
|---|---|
| Tensión de salida | 20 V |
| Corriente de salida máxima | 50 A |
| Potencia de salida máxima | 1000 W |
| Tensión de entrada (CA) | 208 / 400 / 480 V CA (trifásico) |
| Factor de forma | Montaje en bastidor 1U (2U de altura) |
| Interfaz de comunicación | GPIB, LAN (LXI), USB |
| Regulación de línea de tensión | ≤ 0,01% + 2 mV |
| Regulación de carga de corriente | ≤ 0,01% + 10 mA |
| Rizado y ruido de tensión (pico a pico) | ≤ 50 mV (20 Hz – 20 MHz) |
| Temperatura de funcionamiento | 0 °C a 55 °C |
Keysight (Agilent) N8732A 10V 330A 3300W DC Power Supply Options:
- N8732A - 208 - 190-240 V, 3-Phase Ac, 50/60 HZ Input
- N8732A - 230 - 190-240 V, Single-Phase Ac, 50/60 HZ Input
- N8732A - 400 - 380-415 V, 3-Phase Ac, 50/60 HZ Input
| Model | N8732A |
|---|
Keysight (Agilent) N8732A 10V 330A 3300W DC Power Supply Description: 10V, 330A, 3300W DC output Small, high density 2 U package Built-in voltage and current measurement Full protection from over-voltage and over-current LAN, USB, and GPIB interfaces standard The Keysight (Agilent) Technologies N8700 series system DC power supplies give you just the right performance at just the right price in a compact (2 U) package. This family of affordable 3300 W and 5000 W single-output programmable DC power supplies consists of 21 models for simple DC power applications. They provide stable output power, built-in voltage and current measurement, and output voltage and current from 8 V to 600 V and 5.5 A to 400 A. These economical supplies offer many system-ready features like multiple standard I/O interfaces to simplify and accelerate test-system development for R+D, design validation, and manufacturing engineers in the aerospace/defense, automotive, component and communications industries. The N8700 provides up to 5200 W in a small space-saving 2 U-high, 19- inch-wide package. Its air vents are in the front and rear (not on the top or bottom), so you can stack other instruments directly above or below it to save valuable rack space.
