Keysight Technologies DSOX3032A
| Atributo | Valor |
|---|---|
| Número de canales | 2 canales analógicos |
| Ancho de banda | 300 MHz |
| Frecuencia de muestreo | 2 GSa/s |
| Profundidad de memoria | 2 Mpuntos |
| Pantalla | Pantalla táctil WVGA de 8,5 pulgadas |
| Tasa de actualización de forma de onda | 1.000.000 formas de onda por segundo |
| Resolución vertical | 8 bits |
| Rango de escala vertical | 1 mV/div a 10 V/div |
| Base de tiempos | 1 ns/div a 50 s/div |
| Interfaz de conectividad | USB, LAN (LXI), puerto para módulo de actualización |
Keysight (Agilent) DSOX3032A Options:
- DSOX3032A - DSOX3MEMUP - Memory upgrade (standard 2 Mpts to 4 Mpts)
- DSOX3032A - DSOX3SGM - Segmented memory
- DSOX3032A - DSOX3MSO - MSO upgrade: add 16 digital timing channels (for 500 MHz and below models)
- DSOX3032A - DSOX3WAVEGEN - WaveGen built-in 20 MHz function/arbitrary waveform generator
- DSOXDVM - DSOXDVM - Integrated 3-digit digital voltmeter (DVM)
- DSOX3032A - DSOX3EMBD - Embedded serial triggering and analysis (I2C, SPI)
- DSOX3032A - DSOX3COMP - Computer serial triggering and analysis (RS232/422/485/UART)
- DSOX3032A - DSOX3AUTO - Automotive serial triggering and analysis (CAN, LIN)
- DSOX3032A - DSOX3FLEX - FlexRay serial triggering and analysis
- DSOX3032A - DSOX3AUDIO - Audio serial triggering and analysis (I2S)
- DSOX3032A - DSOX3AERO - Aerospace serial triggering and analysis (MIL-STD 1553, ARINC 429)
- DSOX3032A - DSOX3PWR - Power measurements and analysis application
- DSOX3032A - DSOX3MASK - Mask/limit testing
- DSOX3032A - DSOX3VID - Enhanced video/TV triggering and analysis (HDTV)
- DSOX3032A - DSOX3ADVMATH - Advanced waveform math
- DSOX3032A - DSOXEDK - Educator's oscilloscope training kit
- DSOX3032A - DSOX3BW24 - Bandwidth upgrade: 100 MHz to 200 MHz, 4 ch, License only
- DSOX3032A - DSOX3BW52 - Bandwidth upgrade: 350 MHz to 500 MHz, 2 ch, License only
- DSOX3032A - DSOX3BW54 - Bandwidth upgrade: 350 MHz to 500 MHz, 4 ch, License only
- DSOX3032A - DSOX3BW32 - Bandwidth upgrade: 100 MHz to 350 MHz, 2 ch, Service center
- DSOX3032A - DSOX3BW34 - Bandwidth upgrade: 200 MHz to 350 MHz, 4 ch, Service center
- DSOX3032A - DSOX3BW12 - Bandwidth upgrade: 500 MHz to 1 GHz, 2 ch, Service center
- DSOX3032A - DSOX3BW14 - Bandwidth upgrade: 500 MHz to 1 GHz, 4 ch, Service center
- DSOX3032A - DSOXLAN - LAN/VGA connection module
- DSOX3032A - DSOXGPIB - GPIB connection module
| Model | DSOX3032A |
|---|
El osciloscopio Keysight (Agilent) DSOX3032A es un dispositivo de 2 canales de la serie InfiniiVision 3000 X, que ofrece un ancho de banda de 350 MHz y muestreo de hasta 4 GSa/s. Integra cinco instrumentos en uno: osciloscopio, canales digitales, generador de señales, voltímetro y analizador de protocolos, con una tasa de actualización superior a un millón de formas de onda por segundo y pantalla WVGA de 8,5 pulgadas.
Con su memoria inteligente MegaZoom IV, ancho de banda ampliable hasta 1 GHz y sistemas de disparo y adquisición flexibles, es ideal para el análisis de formas de onda complejas y la depuración de sistemas embebidos.
Testwall puede suministrar el Keysight (Agilent) DSOX3032A usado, completamente probado. Con soporte experto y entrega global, Testwall garantiza instrumentación de alto rendimiento con fiabilidad y calidad de servicio inigualables. Contáctenos directamente si necesita calibración o reparación del Keysight (Agilent) DSOX3032A.
