Keysight Technologies MSOX6002A
| Atributo | Valor |
|---|---|
| Ancho de banda | 1 GHz |
| Número de canales analógicos | 2 |
| Canales digitales | 16 canales lógicos digitales |
| Frecuencia de muestreo máxima | 5 GSa/s |
| Profundidad de memoria | 4 Mpuntos por canal |
| Tasa de actualización de forma de onda | 1.000.000 de formas de onda por segundo |
| Pantalla | Pantalla táctil capacitiva de 12,1 pulgadas WXGA |
| Resolución vertical | 8 bits (hasta 12 bits en modo de alta resolución) |
| Rango de escala de tiempo | 1 ns/div a 20 s/div |
| Interfaz y conectividad | USB, LAN (LXI), GPIB opcional |
Keysight (Agilent) MSOX6002A Options:
- MSOX6002A - DSOX6B10T252BW - 1.0 to 2.5 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6B10T402BW - 1.0 to 4.0 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6B10T602BW - 1.0 to 6.0 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6B25T402BW - 2.5 to 4.0 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6B25T602BW - 2.5 to 6.0 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6B40T602BW - 4.0 to 6.0 GHz bandwidth upgrade, 2 ch, fixed perpetual license
- MSOX6002A - DSOX6APPBNDL - Software application bundle (includes all software applications)
- MSOX6002A - DSOX6AERO - MIL-STD 1553 and ARINC 429 serial triggering and analysis
- MSOX6002A - DSOX6AUDIO - Audio serial triggering and analysis (I2S)
- MSOX6002A - DSOX6AUTO - Automotive serial triggering and analysis (CAN, CAN-dbc, CAN-FD, LIN)
- MSOX6002A - DSOX6COMP - Computer serial triggering and analysis (RS232/UART)
- MSOX6002A - DSOX6EMBD - Embedded serial triggering and analysis (I2C, SPI)
- MSOX6002A - DSOX6FLEX - FlexRay serial triggering and analysis
- MSOX6002A - DSOX6SENSOR - SENT (Single Edge Nibble Transmission) triggering and analysis
- MSOX6002A - DSOX6USBFL - USB 2.0 Full/Low Speed serial decode and triggering
- MSOX6002A - DSOX6USBH - USB 2.0 Hi-Speed serial decode and triggering
- MSOX6002A - DSOXDVMCTR - Integrated digital voltmeter and 10 digit counter
- MSOX6002A - DSOX6FPGAX - FPGA dynamic probe option for Xilinx
- MSOX6002A - DSOX6JITTER - Jitter and real time eye diagram analysis
- MSOX6002A - DSOX6MASK - Mask limit testing
- MSOX6002A - DSOX6PWR - Power analysis application
- MSOX6002A - DSOX6USBSQ - USB 2.0 signal quality test
- MSOX6002A - DSOX6VID - Enhanced video/TV application package
- MSOX6002A - DSOX6WAVEGEN2 - Dual channel WaveGen 20 MHz AWG
- MSOX6002A - DSOX6MSO - InfiniiVision 6000 X-Series oscilloscope MSO upgrade
- MSOX6002A - DSOXEDK - Education and training kit
- MSOX6002A - N8900A - Infiniium offline oscilloscope analysis software
- MSOX6002A - BV0000A - BenchVue software
| Model | MSOX6002A |
|---|
El Keysight (Agilent) MSOX6002A es un osciloscopio de señal mixta de alto rendimiento que ofrece un ancho de banda analógico de 2 GHz y una tasa de muestreo de 20 GSa/s, con 2 canales analógicos y 16 digitales para un análisis completo de señales.
Cuenta con una pantalla táctil capacitiva de 12,1 pulgadas, matemáticas de forma de onda en tiempo real, decodificación serial, modo de múltiples ventanas y herramientas avanzadas de análisis lógico para depuración de sistemas embebidos de alta velocidad.
Testwall puede suministrar el Keysight (Agilent) MSOX6002A usado, totalmente probado. Con soporte experto y entrega global, Testwall garantiza instrumentación de alto rendimiento con una fiabilidad y calidad de servicio inigualables. Contáctenos directamente si necesita calibración o reparación del Keysight (Agilent) MSOX6002A.
