Magna Power TSA800-24
| Atributo | Valor |
|---|---|
| Tensión de salida | 800 VDC |
| Corriente de salida | 24 A |
| Potencia de salida | 19.200 W (19,2 kW) |
| Tensión de entrada | 208/240 VAC trifásico |
| Regulación de tensión | 0,05% de la tensión nominal |
| Regulación de corriente | 0,1% de la corriente nominal |
| Rizado y ruido (tensión) | 0,5% de la tensión nominal (valor eficaz) |
| Interfaz de control | Analógica, RS-232, RS-485, GPIB (opcional), Ethernet (opcional) |
| Modo de operación | Tensión constante (CV) / Corriente constante (CC) |
| Dimensiones (U de rack) | 3U |
Magna Power TSA800-24 Options:
- TSA800-24 - SP - 208/240 Vac Single-Phase Input (5 kW Only)
- TSA800-24 - CAB1 - Cabinet and Integration (32" x 24" x 31.5", 12U)
- TSA800-24 - CAB2 - Cabinet and Integration (51.5" x 24" x 31.5", 24U)
- TSA800-24 - CAB3 - Cabinet and Integration (67" x 24" x 31.5", 30U)
- TSA800-24 - CAB4 - Cabinet and Integration (75" x 24" x 31.5", 36U)
- TSA800-24 - +ISO - High Isolation Output
- TSA800-24 - +HS - High Slew Rate Output
- TSA800-24 - +GPIB - IEEE-488 GPIB Interface
- TSA800-24 - +LXI - LXI TCP/IP Ethernet Interface
- TSA800-24 - PPPE - Photovoltaic Power Profile Emulation
- TSA800-24 - RS485 - RS-485 Converter
- TSA800-24 - UID - UID47: Universal Interface Device
- TSA800-24 - USB - USB Edgeport Converter
- TSA800-24 - +WC - Water Cooling
| Model | TSA800-24 |
|---|
MAGNA-POWER TSA800-24 DC Power Supply
Magna-Power Electronics TSA800-24 provides a wide voltage and cur range while still maintaining among the highest power density rack-mount packaging. The TSA800-24 covers voltages up to 800 Vdc (floating) and cur levels up to 24 Adc. All TS Series power supplies come standard with isolated 37-pin external I/O, RS232, Remote Interface Software, IVI drivers for integration into a variety of programming environments. The A Version front panel provides a digital display with rotary front panel input, isolated 37-pin analog/digital I/O, and a RS232 computer interface.
All TS Series Magna-Power DC power supplies come with a dedicated National Instruments LabVIEW driver, Interchangeable Virtual Instrument (IVI) driver, and support for a wide range of Standard Commands for Programmable Instrumentation (SCPI). Magna-Power Electronics programmable DC power supplies are designed to be as versatile and expandable as possible. A variety of options are available allowing the product to deviate from its standard specifications.
Specifications for the MAGNA-POWER TSA800-24 DC Power Supply Include:
| Voltage | 800V |
| Current | 24A |
| Power | 20 kW |
| Efficiency | ‰¥ 86% at full load |
