Rigol
Rigol DSA832-TG
3.2 GHz Spectrum Analyzer
9 kHz – 3,2 GHz Rango de Frecuencia
Integrado, rango de 100 kHz a 3,2 GHz Generador de Seguimiento
10 Hz – 1 MHz (en pasos de 1-3-10) Ancho de Banda de Resolución (RBW)
-161 dBm/Hz (típico, con preamp activado) Nivel de Ruido Promedio Mostrado (DANL)
80 dB Rango Dinámico
| Atributo | Valor |
|---|---|
| Rango de Frecuencia | 9 kHz – 3,2 GHz |
| Generador de Seguimiento | Integrado, rango de 100 kHz a 3,2 GHz |
| Ancho de Banda de Resolución (RBW) | 10 Hz – 1 MHz (en pasos de 1-3-10) |
| Nivel de Ruido Promedio Mostrado (DANL) | -161 dBm/Hz (típico, con preamp activado) |
| Rango Dinámico | 80 dB |
| Nivel Máximo de Entrada | +30 dBm (con atenuador de entrada) |
| Fase de Ruido | -98 dBc/Hz @ 10 kHz de separación (típico) |
| Pantalla | Pantalla LCD TFT de 8 pulgadas, resolución 800 × 480 |
| Interfaces de Conectividad | USB Host, USB Device, LAN (Ethernet), GPIB (opcional) |
| Preamplificador Interno | Sí, integrado (frecuencia de operación: 100 kHz – 3,2 GHz) |
| Model | DSA832-TG |
|---|
For design and development implementing Wi-Fi, Bluetooth, and other RF standards, the SSB Phase Noise down as low as -98 dBc/Hz at a 10 KHz offset empowers engineers to more accurately analyze modulations and noise surrounding their signals of interest. This becomes important for debugging and immunity testing of transceiver systems. The 7.5 GHz instrument enables engineers to investigate the 3rd harmonic of all of their critical 2.4 GHz applications while the 3.2 GHz models enable primary investigation of those signals as well as EMC measurements past the 3 GHz threshold. Additionally, resolution bandwidth settings down to 10 Hz means more precise visualization of low power RF signals. Whether you are still debugging your RF transceiver set, designing layout and configuration changes to maximize efficiency, or testing your system in noisy environments the DSA800 series spectrum analyzers will help you to quickly and easily identify and analyze your areas of concern.
