Sorensen
Sorensen DCS8-125E
8-125A DC Power Supply
0 - 8 V Tensión de salida
0 - 125 A Corriente de salida
1000 W Potencia máxima
115/230 V CA, monofásico Tensión de entrada
47 - 63 Hz Frecuencia de entrada
| Atributo | Valor |
|---|---|
| Tensión de salida | 0 - 8 V |
| Corriente de salida | 0 - 125 A |
| Potencia máxima | 1000 W |
| Tensión de entrada | 115/230 V CA, monofásico |
| Frecuencia de entrada | 47 - 63 Hz |
| Regulación de línea (tensión) | 0,01% + 2 mV |
| Regulación de carga (corriente) | 0,01% + 3 mA |
| Rizado y ruido (tensión) | 1 mV RMS típico |
| Dimensiones (An x Al x Pr) | 425 mm x 133 mm x 635 mm (3U) |
| Peso | 20,4 kg |
Sorensen DCS8-125E Options:
- DCS8-125E - M1 - Factory configured for 115 VAC input (1 kW and 1.2 kW units only)
- DCS8-125E - M9C - Internal IEEE-488/RS 232 Interface Card with voltage and current readback and adjustable OVP (May not be combined with M51A or M85)
- DCS8-125E - M13 - Locking shafts (front panel potentiometers)
- DCS8-125E - M32 - Master/slave paralleling cable configured for two or more units
- DCS8-125E - M51A - Isolated analog programming control of V/I/OVP and isolated V/I monitor and status outputs up to 500V relative to the supply's return line (May not be combined with M9C or M85)
- DCS8-125E - M85 - Multichannel slave interface allows use of a single GPIB address (using 1 master unit with M9C option) to control multiple units via a standard RS485 connector, 3 ft. connector included (May not be combined with M9C or M51A)
| Model | DCS8-125E |
|---|
