Sorensen SGI60-417
| Atributo | Valor |
|---|---|
| Tensión de salida | 60 V |
| Corriente de salida | 417 A |
| Potencia máxima | 25.000 W |
| Tipo de fuente de alimentación | Fuente de alimentación de CC programable |
| Regulación de tensión en línea | 0,01% + 2 mV |
| Regulación de corriente en línea | 0,01% + 2 mA |
| Interfaz de control | Analógica / Programable |
| Tensión de entrada (CA) | 208/240 V CA, trifásica |
| Rizado y ruido (tensión) | 50 mV pico a pico |
| Temperatura de funcionamiento | 0 °C a 50 °C |
Sorensen SGI60-417 Options:
- SGI60-417 - C - Input Voltage 187 / 242VAC, 3 Phase
- SGI60-417 - D - Input Voltage 342 / 440VAC, 3 Phase
- SGI60-417 - E - Input Voltage 396 / 528VAC, 3 Phase
- SGI60-417 - 0A - No Remote Control Option
- SGI60-417 - 1A - IEEE-488.2 + RS-232C
- SGI60-417 - 1C - Ethernet + RS-232C
- SGI60-417 - 1D - Isolated Analog Control
- SGI60-417 - 2A - Combined Options 1A+1D
- SGI60-417 - 2G - Combined Options 1C+1D
- SGI60-417 - AA - No Process Option
- SGI60-417 - AB - Certificate of Calibration to ANSI / NCSL Z540-1 (includes Test Data)
- SGI60-417 - AJ - Front panel dust filter - factory installed - 3U unit only
- SGI60-417 - CV - 400Hz AC input @ 208 VAC (does not carry CE, CSA or UL marks) (6U only) STD on 3U
- SGI60-417 - PF - Passive power factor correction to 0.9 (Only applicable to 40V, 60V to 800V)
- SGI60-417 - R - RoHS Compliant Version
| Model | SGI60-417 |
|---|
SORENSEN SGI60-417 DC Power Supply
The Sorensen SGI60-417 DC Power Supply represents the next generation of high power programmable DC power supplies. It is designed for exceptional load transient response, low noise and the highest power density in the industry. The power density is enhanced by a stylish front air intake allowing supplies to be stacked without any required clearance between units. Depending on the output voltage, one to six modules can be configured in a single chassis to deliver 5 kW to 30 kW of power. Combinations of these chassis can then be easily paralleled to achieve power levels up to 150 kW. Paralleled units operate like one single supply providing total system current.
The Sorensen SGI60-417 DC Power Supply combines onboard advanced intelligent controls "SGI" (Sorensen General purpose Intelligent) with the outstanding power electronics common to all SG family supplies. These controls enable sophisticated sequencing, constant power mode and save/recall of instrument settings. Looping of sequences makes the SGI is ideal for repetitive testing. An impressive vacuum fluorescent graphical display in eight languages, context sensitive €œsoft " keys and front panel keyboard simplify programming of the SGI.
Specifications for the SORENSEN SGI60-417 DC Power Supply Include:
| Voltage | 60 V |
| Current | 417 A |
| Total Power | 20/25 kW |
| Efficiency | 87 % typical at nominal line and max load |
