Sorensen
Sorensen XT120-0.5
Programmable DC Power Supply
120 V Tensión de salida máxima
0,5 A Corriente de salida máxima
60 W Potencia máxima de salida
CC (Corriente Continua) Tipo de salida
0,01% + 2 mV Regulación de tensión en línea
| Atributo | Valor |
|---|---|
| Tensión de salida máxima | 120 V |
| Corriente de salida máxima | 0,5 A |
| Potencia máxima de salida | 60 W |
| Tipo de salida | CC (Corriente Continua) |
| Regulación de tensión en línea | 0,01% + 2 mV |
| Regulación de corriente en línea | 0,01% + 250 µA |
| Tensión de rizado y ruido | 1 mV RMS / 5 mV pico a pico |
| Tensión de entrada | 100 - 240 V CA, 50/60 Hz |
| Interfaz de comunicación | USB, RS-232, GPIB (opcional) |
| Dimensiones (An x Al x Pr) | 88,9 mm x 133,4 mm x 381 mm |
Sorensen XT120-0.5 Options:
- XT120-0.5 - M1 - Power Input Modification: 110V ±10%, 47-63 Hz
- XT120-0.5 - M2 - Power Input Modification: 220V ±10%, 47-63 Hz
- XT120-0.5 - M3 - Power Input Modification: 230V ±10%, 47-63 Hz
- XT120-0.5 - M4 - Power Input Modification: 240V ±10%, 47-63 Hz
- XT120-0.5 - M5A - Analog Programming: Internal interface for full scale remote programming of output voltage and/or current by a 0-10V or 0-10 kΩ external source connected at the rear panel. Includes 0-10V readback, externally adjustable offset and range, front panel adjustable overvoltage protection (OVP), TTL shutdown with selectable logic, master/slave tracking and status signals for programming mode, operating mode, OVP and output fail flag. (May not be combined with M9B)
- XT120-0.5 - M9B - Internal IEEE-488 Interface: Features complete remote programming, including status reporting, settings query and interrupt generation with user designated fault conditions. Both the voltage and current output are precisely programmed directly in volts and amps. (May not be combined with M5A)
- XT120-0.5 - M11 - 10-turn current control potentiometer
- XT120-0.5 - M13 - Locking shafts (front panel potentiometer)
- XT120-0.5 - RM-XHS - Rack Adapter Kit
| Model | XT120-0.5 |
|---|
