Tektronix MSO5204
4+16-CH, DIGITAL, 2GHz Mixed Signal Oscilloscope
2 GHz Ancho de banda
4 Número de canales analógicos
16 Canales digitales
10 GS/s Frecuencia de muestreo máxima
125 M puntos Longitud de registro
| Atributo | Valor |
|---|---|
| Ancho de banda | 2 GHz |
| Número de canales analógicos | 4 |
| Canales digitales | 16 |
| Frecuencia de muestreo máxima | 10 GS/s |
| Longitud de registro | 125 M puntos |
| Resolución vertical | 8 bits (12 bits en modo de alta resolución) |
| Pantalla | Pantalla táctil capacitiva de 15,6 pulgadas HD (1920 x 1080) |
| Tasa de captura de formas de onda | 500.000 formas de onda por segundo |
| Sensibilidad vertical | 1 mV/div a 10 V/div |
| Conectividad | USB, LAN (LXI), DisplayPort, puerto de sonda auxiliar |
Tektronix MSO5204 Options:
- MSO5204 - 2RL - Record Length: 250M max, 125M/Ch
- MSO5204 - 5RL - Record Length: 125M max (4 ch), 250M max (1 or 2 ch) - wait, per datasheet: 125M max, 50M/Ch for MSO5034/5054; for MSO5104/5204: 125M max, 50M/Ch
- MSO5204 - 2RL - Record Length upgrade: 50M max, 25M/Ch (all ch) / 50M (1 or 2 ch)
- MSO5204 - 5RL - Record Length upgrade: 125M max, 50M/Ch
- MSO5204 - 10RL - Record Length upgrade: 250M max, 125M/Ch
- MSO5204 - SSD - Solid State Hard Disk Drive, ≥300 GB
- MSO5204 - DDRA - DDR Memory Bus Analysis (requires Opt. DJA; available on 1 GHz and 2 GHz models only)
- MSO5204 - DJA - Jitter and Eye Analysis Tools – Advanced (DPOJET)
- MSO5204 - ET3 - Ethernet Compliance Testing (requires TF-GBE-BTP or TF-GBE-ATP Ethernet Test Fixture)
- MSO5204 - LT - Waveform Limit Testing
- MSO5204 - MOST - MOST Essentials – Electrical Compliance and Debug Test Solution for MOST50 and MOST150 (requires Opt. DJA)
- MSO5204 - MTM - Mask Testing
- MSO5204 - PWR - Power Measurement and Analysis
- MSO5204 - SR-AERO - Aerospace Serial Triggering and Analysis (MIL-STD-1553)
- MSO5204 - SR-AUTO - Automotive Serial Triggering and Analysis (CAN/LIN/FlexRay)
- MSO5204 - SR-COMP - Computer Serial Triggering and Analysis (RS-232/422/485/UART)
- MSO5204 - SR-CUST - Custom Serial Analysis Kit for Developers
- MSO5204 - SR-DPHY - MIPI D-PHY Serial Analysis (DSI-1 and CSI-2)
- MSO5204 - SR-EMBD - Embedded Serial Triggering and Analysis (I2C, SPI)
- MSO5204 - SR-ENET - Ethernet Serial Triggering and Analysis (10BASE-T, 100BASE-TX)
- MSO5204 - SR-PCIE - PCI Express Serial Analysis (available on ≥1 GHz models only)
- MSO5204 - SR-USB - USB 2.0 Serial Triggering and Analysis (LS, FS, HS)
- MSO5204 - SR-810B - 8b/10b Serial Analysis
- MSO5204 - SVE - SignalVu Essentials – Vector Signal Analysis Software
- MSO5204 - SVA - SignalVu AM/FM/Direct Audio Measurements (requires Opt. SVE)
- MSO5204 - SVM - SignalVu General-purpose Modulation Analysis (requires Opt. SVE)
- MSO5204 - SVP - SignalVu Pulse – Advanced Signal Analysis (requires Opt. SVE)
- MSO5204 - SVT - SignalVu Settling Time Measurements – Frequency and Phase (requires Opt. SVE)
- MSO5204 - USB - USB 2.0 Compliance Testing (requires TDSUSBF USB Test Fixture; 2 GHz bandwidth required for high-speed USB)
- MSO5204 - VET - Visual Trigger and Search
- MSO5204 - VNM - CAN/LIN Protocol Analysis Software
- MSO5204 - PS1 - Power Solution Bundle: DPOPWR, P5205A, TCP0030, TPA-BNC, 067-1686-xx (Deskew Fixture)
- MSO5204 - PS2 - Power Solution Bundle: DPOPWR, THDP0200, TCP0030, 067-1686-xx (Deskew Fixture)
- MSO5204 - PS3 - Power Solution Bundle: DPOPWR, TMDP0200, TCP0020, 067-1686-xx (Deskew Fixture)
- MSO5204 - A0 - Power Plug: North America
- MSO5204 - A1 - Power Plug: Universal European Union
- MSO5204 - A2 - Power Plug: UK
- MSO5204 - A3 - Power Plug: Australia
- MSO5204 - A5 - Power Plug: Switzerland
- MSO5204 - A6 - Power Plug: Japan
- MSO5204 - A10 - Power Plug: China
- MSO5204 - A11 - Power Plug: India
- MSO5204 - A12 - Power Plug: Brazil
- MSO5204 - A99 - No power cord
- MSO5204 - L0 - English manual
- MSO5204 - L1 - French manual
- MSO5204 - L3 - German manual
- MSO5204 - L5 - Japanese manual
- MSO5204 - L7 - Simplified Chinese manual
- MSO5204 - L8 - Traditional Chinese manual
- MSO5204 - L9 - Korean manual
- MSO5204 - L10 - Russian manual
- MSO5204 - 99 - No manual
- MSO5204 - C3 - Calibration Service 3 Years
- MSO5204 - C5 - Calibration Service 5 Years
- MSO5204 - D1 - Calibration Data Report
- MSO5204 - D3 - Calibration Data Report 3 Years (with Opt. C3)
- MSO5204 - D5 - Calibration Data Report 5 Years (with Opt. C5)
- MSO5204 - G3 - Complete Care 3 Years (includes loaner, scheduled calibration, and more)
- MSO5204 - G5 - Complete Care 5 Years (includes loaner, scheduled calibration, and more)
- MSO5204 - R3 - Repair Service 3 Years (including warranty)
- MSO5204 - R5 - Repair Service 5 Years (including warranty)
| Model | MSO5204 |
|---|
El Tektronix MSO5204 ofrece un ancho de banda de 2 GHz, velocidad de muestreo de 10 GS/s y memoria de 12,5 Mpts para una fidelidad de señal superior. Con cuatro canales analógicos y dieciséis digitales, proporciona análisis precisos de diseños de alta velocidad. El sistema operativo Windows y los disparadores visuales facilitan el diagnóstico.
Ideal para ingenieros con márgenes de tiempo ajustados y altas velocidades, admite decodificación de protocolos en serie e integración de laboratorio.
Testwall puede suministrar el Tektronix MSO5204 usado, completamente probado. Con soporte experto y entrega global, Testwall garantiza instrumentos de alto rendimiento con fiabilidad. Contáctenos para calibración o reparación del Tektronix MSO5204.
