Tektronix TSO8C18
| Atributo | Valor |
|---|---|
| Número de canales | 18 canales digitales |
| Velocidad máxima de muestreo | 121,2 MS/s |
| Profundidad de memoria por canal | 2 Mpts |
| Umbral de voltaje ajustable | -2,5 V a +5,5 V |
| Resolución de tiempo mínima | 8,25 ns |
| Compatibilidad | Osciloscopios Tektronix serie MSO/DPO5000B y MSO/DPO70000 |
| Tipo de sonda | Módulo de sonda lógica digital |
| Tensión de entrada máxima | ±42 V (pico) |
| Impedancia de entrada | 101 kΩ en paralelo con 3 pF |
| Longitud del cable de la sonda | 0,3 m |
Tektronix TSO8C18 Options:
- TSO8C18 - L0 - English manual
- TSO8C18 - L5 - Japanese manual
- TSO8C18 - L7 - Simplified Chinese manual
- TSO8C18 - L9 - Korean manual
- TSO8C18 - G3 - Three Year Gold Care Plan. Includes expedited repair of all product failures including ESD and EOS, access to a loaner product during repair or advanced exchange to reduce downtime, priority access to Customer Support among others
- TSO8C18 - G5 - Five Year Gold Care Plan. Includes expedited repair of all product failures including ESD and EOS, access to a loaner product during repair or advanced exchange to reduce downtime, priority access to Customer Support among others
- TSO8C18 - R3 - Standard Warranty Extended to 3 Years. Covers parts, labor and 2-day shipping within country. Guarantees faster repair time than without coverage. All repairs include calibration and updates.
- TSO8C18 - R5 - Standard Warranty Extended to 5 Years. Covers parts, labor and 2-day shipping within country. Guarantees faster repair time than without coverage. All repairs include calibration and updates.
- TSO8C18 - C3 - Calibration service 3 years. Includes traceable calibration or functional verification where applicable. Coverage includes the initial calibration plus 2 years calibration coverage
- TSO8C18 - C5 - Calibration service 5 years. Includes traceable calibration or functional verification where applicable. Coverage includes the initial calibration plus 4 years calibration coverage
- TSO8C18 - D1 - Calibration Data Report
- TSO8C18 - D3 - Calibration Data Report 3 Years (with Option C3)
- TSO8C18 - D5 - Calibration Data Report 5 Years (with Option C5)
| Model | TSO8C18 |
|---|
TEKTRONIX TSO8C18 Optical Module
The Tektronix TSO8C18 Optical Module provides > 30 GHz optical bandwidth, plus fully integrated Optical Reference Receivers (ORR)1 enabling both single mode and multi-mode conformance testing at 850 nm, 1310 nm, and 1550 nm bands. The TSO8C18 offers Accurate testing and characterization of short or long wave optical signals using the high sensitivity and low noise performance.
The Tektronix TSO8C18 Optical Module is equipped with user configurable bandwidth supported through Bandwidth Enhancement (BWE) filters. Extend the TSO8C18 optical bandwidth up to 35 GHz in 0.0001 GHz increments for precise control. The Optical reference receivers (ORR) supports specified requirements for standards-mandated compliance testing and the extinction ratio measurements with built-in variable ER correction ensure accuracy and repeatability. The TSO8C18 optical module features high input sensitivity for measurement of low power signals. This enables the user to recover full pattern acquisitions with little noise contribution from the oscilloscope, making it possible to take true and accurate measurements in conditions where signal power is low.
Specifications for the TEKTRONIX TSO8C18 Optical Module Include:
| Optical Channels | Two (2) Ch. |
| Wavelength Range | 750 to 1650 nm |
| Unfiltered Optical Bandwidth (Multi/Single Mode) | 30 GHz / >30 GHz |
| Optical Return Loss (Multi/Single Mode) | >16 dB |
