Vitrek V73
| Atributo | Valor |
|---|---|
| Rango de voltaje de prueba | Hasta 10 kV CC / 10 kV CA |
| Corriente de medición | Hasta 10 mA |
| Modos de prueba | Resistencia de aislamiento (IR), Hipot CC, Hipot CA, Resistencia de tierra (GR) |
| Resolución de resistencia de aislamiento | Hasta 200 TΩ |
| Precisión de voltaje | ±1% del valor indicado |
| Interfaz de comunicación | USB, RS-232, GPIB (opcional) |
| Pantalla | Pantalla LCD gráfica de alta resolución |
| Almacenamiento de resultados | Memoria interna para almacenamiento de resultados de prueba |
| Alimentación eléctrica | 100–240 V CA, 50/60 Hz |
| Cumplimiento normativo | CE, UL, conforme a normas IEC 61010 |
Vitrek V73 Options:
- V73 - V7X-230V - Factory Set for 230V Line
- V73 - QT Pro 7 - QuickTest Software
- V73 - TL-115-1 - 115V Receptacle Hipot Test Adaptor
- V73 - TL-115-2 - 115V Receptacle Hipot & GB Test Adaptor
- V73 - TL-209 - Additional HV/Continuity Test Lead set
- V73 - K-2R - Additional Ground Bond Lead Set
- V73 - HVW-7 - High Voltage Warning Light
- V73 - RSS-7 - Remote Start Switch
- V73 - RSF-7 - Remote Start Footswitch
- V73 - TL-TP1 - High Voltage Test Pistol
- V73 - HC-V7X - Hard Carrying Case with Die Cut Foam
| Model | V73 |
|---|
VITREK V73 Electrical Safety Compliance Analyzer
The Vitrek V73 Electrical Safety Compliance Analyzer introduces a cutting-edge multi-function hipot tester that combines powerful performance with a compact design, all at an entry-level price point. With an easy-to-use Touch user interface, high reliability, and fan-free construction, the V73 redefines hipot testing experience.
The Vitrek V73 model offers 6 functions to choose from, including AC/DC Hipot, IR, Ground Bond, Continuity, and Built-in Switching. It supports various interfaces such as USB 2.0, Serial/RS232, and Digital I/O. With features like adjustable Insulation Resistance, multi-mode IR, and test memory storage, the V73 Series sets a new standard for hipot testers, ensuring accuracy, safety, and reliability in compliance with safety tester requirements.
Specifications for the VITREK V73 Electrical Safety Compliance Analyzer Include:
| AC Voltage Range | 10 to 5000 V RMS, 50/60 Hz |
| DC Voltage Range | 20 to 5000 V |
| IR Voltage Range | 20 to 5000 VDC |
| Max Cur AC/DC | 20 mArms / 10 mA |
