Exfo
Exfo IQS-5100B
Polarization Scrambler.
1260 nm to 1650 nm Wavelength Range
Up to 55 dB Dynamic Range
-80 dBm to +10 dBm Measurement Range
±0.01 nm Wavelength Accuracy
±0.4 dB Power Accuracy
| Attribute | Value |
|---|---|
| Wavelength Range | 1260 nm to 1650 nm |
| Dynamic Range | Up to 55 dB |
| Measurement Range | -80 dBm to +10 dBm |
| Wavelength Accuracy | ±0.01 nm |
| Power Accuracy | ±0.4 dB |
| Spectral Resolution | 0.07 nm (3 dB bandwidth) |
| Interface/Platform | Compatible with EXFO IQS-600 and IQS-500 mainframes |
| Fiber Connector Type | FC/PC (standard), adaptable to SC, LC, ST |
| Sweep Speed | Up to 100 nm/s |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
Exfo IQS-5100B Options:
- IQS-5100B - EI-EUI-28 - Output Connector UPC/DIN 47256
- IQS-5100B - EI-EUI-89 - Output Connector UPC/FC narrow key
- IQS-5100B - EI-EUI-91 - Output Connector UPC/SC
- IQS-5100B - EI-EUI-95 - Output Connector UPC/E-2000
| Model | IQS-5100B |
|---|
The Exfo IQS-5100B is a polarization scrambler.
