Fluke 568-EX
| Attribute | Value |
|---|---|
| Temperature Range | -40°C to 800°C (-40°F to 1472°F) |
| Accuracy | ±1°C or ±1% (whichever is greater) for infrared; ±0.5°C or ±0.5% for thermocouple |
| Distance-to-Spot Ratio | 50:1 |
| Emissivity | Adjustable from 0.10 to 1.00 |
| Thermocouple Input | Type K thermocouple input included |
| Safety Rating | Intrinsically safe; ATEX and IECEx certified for use in hazardous locations (Zone 1, Zone 21) |
| Display | Backlit LCD display for visibility in low-light environments |
| Laser | Dual laser sighting for precise targeting |
| Response Time | 500 milliseconds |
| Battery Life | Approximately 8 hours of continuous use with 9V alkaline battery |
| Model | 568-EX |
|---|
Fluke 568-EX Intrinsically Safe Mini Infrared Thermometer
The Fluke 568-EX Intrinsically Safe Mini Infrared Thermometer is the one product which can use in Class I Div 1 and Div 2 or Zone 1 and 2 hazardous environments anywhere in the world. With a straight-forward user interface and soft key menus, the Fluke 568 Ex makes even complex measurements very easy. With just a few pushes of a button, users can adjust emissivity, record data, or turn on and off alarms. All in a single intrinsically safe tool certified by major rating bodies from around the world.
Fluke 568-EX Intrinsically Safe Mini Infrared Thermometer confidently measures a wide variety of surfaces with the adjustable emissivity feature, including a built-in material table. The 50:1 distance-to-spot ratio allows users to measure smaller objects from further away. It is also compatible with mini-connector K-type thermocouple (KTC) probe. Fluke 568-EX can captures up to 99 points of data for quick downloading to a PC through the USB connection. Featuring rugged and ergonomic design, Fluke 568 is built to withstand tough industrial, electrical, HVAC, and mechanical environments.
Specifications for the Fluke 568-EX Intrinsically Safe Mini Infrared Thermometer Include:
| Infrared temperature range | -40 °C to 800 °C (-40 °F to 1472 °F) |
| Display resolution | 0.1 °C / 0.1 °F |
| Infrared spectral response | 8 µm to 14 µm |
| Infrared response time | < 500 msec |
