Fluke 700P03
| Attribute | Value |
|---|---|
| Pressure Range | 0 to 15 psi (0 to 1 bar) |
| Pressure Type | Gauge |
| Accuracy | ±0.05% of full scale |
| Output Signal | 0.005 VDC per psi |
| Supply Voltage | 12 to 36 VDC |
| Operating Temperature | -20°C to 85°C (-4°F to 185°F) |
| Pressure Port Connection | 1/4-18 NPT Male |
| Wetted Materials | 316L Stainless Steel |
| Electrical Connection | DIN 43650 Connector |
| Compatible Instruments | Fluke 700 Series Pressure Calibrators |
| Model | 700P03 |
|---|
Fluke 700P03 Differential Pressure Module
The Fluke 700P03 Differential Pressure Module allows to measure pressure with the Fluke 700 Series Process Calibrators. It displays pressure readings in any of 10 diffe pressure units specified in the calibrator setup. This differential pressure module has two pressure fittings and measures the difference between the applied pressure on the high fitting versus the low fitting. Fluke 700P03 Differential Pressure Module functions like a gauge module when the low fitting is open.
Fluke 700P03 Differential Pressure Module features internal temperature compensation from 0 °C to 50 °C for full-accuracy performance. The pressure module measures pressure using an internal microprocessor. It receives operating power from and sends digital information to the calibrator. This module can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit, a PC, and a precision pressure source. Rugged urethane molded case of Fluke 700P03 protects the module from rough handling and harsh conditions.
Specifications for the Fluke 700P03 Differential Pressure Module Include:
| Resolution | 0.0001 / 0.001 |
| Measurement range | 5 psi / 34 kPa |
| Reference Uncertainty (23 ± 3 °C) | 0.050% |
| Total Uncertainty 1 year | 0.100 |
