Rigol
Rigol DS7024
High quality 4 channel oscilloscope with 200 MHz Bandwidth, 10 GSa/s sample rate, up to 500 Mpts memory depth and a 25.7 cm touchdisplay 1024x600 pixel.
200 MHz Bande passante
4 voies analogiques Nombre de voies
2 GSa/s (temps réel) Taux d'échantillonnage
100 Mpts (standard) Profondeur mémoire
10,1 pouces (écran tactile capacitif) Taille de l'écran
| Attribut | Valeur |
|---|---|
| Bande passante | 200 MHz |
| Nombre de voies | 4 voies analogiques |
| Taux d'échantillonnage | 2 GSa/s (temps réel) |
| Profondeur mémoire | 100 Mpts (standard) |
| Taille de l'écran | 10,1 pouces (écran tactile capacitif) |
| Résolution verticale | 8 bits (12 bits en mode haute résolution) |
| Fréquence de mise à jour de la forme d'onde | 600 000 formes d'onde par seconde |
| Sensibilité verticale | 1 mV/div à 10 V/div |
| Base de temps | 5 ns/div à 5000 s/div |
| Interfaces de connectivité | USB Host, USB Device, LAN (LXI), HDMI |
| Model | DS7024 |
|---|
MSO7000/DS7000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL. Integrating 6 independent instruments into one, the MSO7000/DS7000 series is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1" display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The MSO7000/DS7000 series digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The MSO7000/DS7000 series offers you a flexible and economical solution to address your actual needs.
