Rigol MSO5102

High quality 2 channel oscilloscope with 100 MHz Bandwidth, 8 GSa/s sample rate, up to 200 Mpts memory depth and a 22.9 cm touchdisplay 1024x600 pixel. Upgradable to a MSO with a 16 channel logic analyzer and expandable by a 2 channel waveform generator.
100 MHz Largeur de bande
2 voies Nombre de voies analogiques
16 voies Nombre de voies numériques
8 GSa/s Taux d'échantillonnage maximum
100 Mpts Profondeur mémoire
Attribut Valeur
Largeur de bande 100 MHz
Nombre de voies analogiques 2 voies
Nombre de voies numériques 16 voies
Taux d'échantillonnage maximum 8 GSa/s
Profondeur mémoire 100 Mpts
Taux de capture des formes d'onde 500 000 formes d'onde/s
Résolution verticale 8 bits (12 bits en mode haute résolution)
Taille de l'écran 7 pouces, écran tactile LCD couleur
Résolution de l'écran 800 x 480 pixels
Interfaces de communication USB Host, USB Device, LAN (LXI), HDMI
Rigol MSO5102 Options:
  • MSO5102 - MSO5000-BW1T2 - Bandwidth upgrade, 100 MHz to 200 MHz
  • MSO5102 - MSO5000-BW1T3 - Bandwidth upgrade, 100 MHz to 350 MHz
  • MSO5102 - MSO5000-4CH - Upgrade from 2 to 4 analogue channels
  • MSO5102 - MSO5000-2RL - Memory depth upgrade to 200 Mpts
  • MSO5102 - MSO5000-AWG - Dual-channel 25 MHz arbitrary waveform generator
  • MSO5102 - MSO5000-PWR - Power analysis
  • MSO5102 - MSO5000-COMP - RS-232/UART trigger and decode
  • MSO5102 - MSO5000-EMBD - I²C and SPI trigger and decode
  • MSO5102 - MSO5000-AUTO - CAN and LIN trigger and decode
  • MSO5102 - MSO5000-FLEX - FlexRay trigger and decode
  • MSO5102 - MSO5000-AUDIO - I²S trigger and decode
  • MSO5102 - MSO5000-AERO - MIL-STD-1553 trigger and decode
  • MSO5102 - MSO5000-BND - Application bundle (all decode options, PWR and AWG)
  • MSO5102 - PLA2216 - 16-channel logic probe
Formulaire d'étalonnage Rigol MSO5102

Formulaire de réparation Rigol MSO5102
Maximum file size: 40MB

The MSO5000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL. Integrating 6 independent instruments into one, the MSO5000 series is equipped with super high sample bandwidth ratio of 8 GSa/s, extremely high memory depth of up to 200 Mpts, clear 9" display, excellent waveform capture rate of 500.000 wfms/s, and powerful data analysis functions. Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics. In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The MSO5000 series digital oscilloscope launched by RIGOL this time integrates 7 independent instruments into 1, including one digital oscilloscope, one spectrum analyzer, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer. The MSO5000 series offers you a flexible and economical solution to address your actual needs.
