Rigol MSO5204
High quality 4 channel oscilloscope with 200 MHz Bandwidth, 8 GSa/s sample rate, up to 200 Mpts memory depth and a 22.9 cm touchdisplay 1024x600 pixel.
Upgradable to a MSO with a 16 channel logic analyzer and expandable by a 2 channel waveform generator.
200 MHz Largeur de bande
4 voies Nombre de voies analogiques
16 voies numériques (MSO) Nombre de voies numériques
8 GSa/s (temps réel) Taux d'échantillonnage
200 Mpts Profondeur mémoire
| Attribut | Valeur |
|---|---|
| Largeur de bande | 200 MHz |
| Nombre de voies analogiques | 4 voies |
| Nombre de voies numériques | 16 voies numériques (MSO) |
| Taux d'échantillonnage | 8 GSa/s (temps réel) |
| Profondeur mémoire | 200 Mpts |
| Taille de l'écran | 10,1 pouces, écran tactile capacitif |
| Résolution verticale | 8 bits (12 bits en mode haute résolution) |
| Fréquence de rafraîchissement de la forme d'onde | 500 000 trames/seconde |
| Protocoles de décodage série | I2C, SPI, UART, CAN, LIN et autres |
| Interfaces de connectivité | USB, LAN (LXI), HDMI |
| Model | MSO5204 |
|---|
The MSO5000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology
developed by RIGOL. Integrating 6 independent instruments into one, the MSO5000 series is equipped with super high sample bandwidth ratio of 8 GSa/s, extremely high memory depth of up to 200 Mpts, clear 9" display, excellent waveform capture rate of 500.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today's inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers.
The MSO5000 series digital oscilloscope launched by RIGOL this time integrates 7 independent instruments into 1, including one digital oscilloscope, one spectrum analyzer, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The MSO5000 series offers you a flexible and economical solution to address your actual needs.
