Haefely PCD120
| Attribute | Value |
|---|---|
| Output Voltage Range | Up to 120 kV |
| Test Standard Compliance | IEC 60270, IEEE 400 |
| Measurement Function | Partial Discharge (PD) Detection and Measurement |
| Frequency Range | 9 kHz – 30 MHz |
| Sensitivity | Less than 1 pC |
| Display | Digital display with ellipse and linear time base |
| Input Impedance | 50 Ω |
| Power Supply | 115/230 V AC, 50/60 Hz |
| Coupling Device Compatibility | Compatible with Haefely coupling devices and coupling capacitors |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
Haefely PCD120 Options:
- PCD120 - DEC 5 - Decoupling unit with current compensated inductors for decoupling according to IEC 61000-4-5 and ITU K.44
- PCD120 - DEC 6 - 4 wire decoupling unit with resistors according to ITU K.44
- PCD120 - PCD 122 - Manual version of the PCD 120
- PCD120 - WinFEAT&R - Control and reporting software. Runs under windows 98, NT, ME, 2000, XP
| Model | PCD120 |
|---|
The Haefely PCD120 is a compact coupling/decoupling network designed for EFT/Burst testing. Engineered according to IEC/EN 61000-4-4 standards, it ensures precise disturbance injection while protecting auxiliary systems. Its rugged design and compact footprint deliver consistent, repeatable performance in both laboratory and production environments.
This unit is ideal for compliance testing applications, ensuring reliable results and secure performance across diverse testing setups.
Testwall can supply the used Haefely PCD120, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Haefely PCD120.
